Safety Relief Valve 2 In 15 psi Bronze MPN:1420508
Free Shipping
In Stock
Introducing our state-of-the-art Safety Relief Valve - designed for both low and medium pressure steam systems. Constructed from robust cast bronze for added durability and corrosion resistance, this valve ensures optimal safety and performance in harsh environments. With a factory preset pressure range of 5 to 15 psi and a maximum temperature of 250F, it is ideal for use in industrial and commercial applications. Its MNPT x FNPT connections allow easy installation, while its 3/8 NPT side tapping for drain connection provides convenient maintenance. Say goodbye to cumbersome multiple valves - the Safety Relief Valve combines both pressure relief and a safety valve in one compact package, saving you time, space and money. Use it for boilers or any application where a reliable steam relief is required - and rest easy knowing your system is protected 24/7.
Top product features:
- Bronze construction for durability and corrosion resistance
- Combines pressure relief and safety valve in one compact package
- 3/8 NPT side tapping for drain connection for convenience and maintenance.
Top product applications:
- Industrial and commercial boiler systems
- Pressure relief in steam systems
- Safety valve for protecting boilers and other equipment from overpressure
Technical Specifications
- Item Safety Relief Valve
- Body Material Cast Bronze
- Inlet Type MNPT
- Outlet Type FNPT
- Inlet Size 2 in
- Outlet Size 2 in
- Factory Set Pressure 15 psi
- Pressure Range 5 to 15 psi
- Steam Capacity (Lb./Hr.) 3,150
- Disc Material PTFE
- Overall Height 7 1/8 in
- Application Low Pressure Steam Heating and Supply Boilers
- Seat Material Chrome Plated Seat w/ TFE Coated Brass Disc
- Spring Material Rust Proofed Steel
- Temp. Range 0 Degrees to 250 Degrees F
- Test Lever Yes
- Standards ASME Section IV, CRN, CSA
Manufacturer Details
- Manufacturer: Apollo
- Condensed Mfg Number: 1420508
- MPN: 1420508
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8481400000
- GDS Category Name: Relief Valves
- GDS Family Name: Pressure and Temperature Control Valves
- GDS Segment Name: Plumbing
- UNSPSC: 40141606
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Valves
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Relief valves
- UNSPSC Family ID: 14
- UNSPSC Family Name: Fluid and gas distribution
- UNSPSC Segment ID: 40
- UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on May 6, 2024 12:33pm UTC Category: Pressure and Temperature Control Valves
