Tumbler Switch EDSC Series 1 Gang 2-Pole MPN:EDSC110-R2
Free Shipping
In Stock
The Tumbler Switch EDSC Series from Appleton Electric is designed to enhance safety in industrial environments by preventing arcing during connect and disconnect operations of lighting and light power loads. Made for classified areas where ignitable vapors, gases, and combustible dusts are present, this switch ensures reliable performance in demanding settings such as chemical plants, refineries, and process industries. With a front-operated design, 1 gang, 2-pole, and a durable construction, this switch offers exceptional functionality while also providing numerous benefits such as minimizing the risk of explosion, ensuring easy operation in restricted spaces, and reducing maintenance costs. The Appleton Electric Tumbler Switch EDSC Series is an essential addition to any facility seeking maximum safety and efficiency.
Top product features:
- Arcing prevention during connect and disconnect operations
- Designed for use in classified areas with ignitable vapors and dusts
- Front-operated switch for easy operation in restricted spaces
Top product applications:
- Installation in classified areas with ignitable vapors and dusts, such as chemical plants and refineries
- Use in heavy industrial settings where lighting and power loads require prevention of arcing during connect or disconnect operations
- Applying an additional layer of safety for workers operating within potentially hazardous environments
Technical Specifications
- Item Tumbler Switch
- Type of Operator Front Operated
- Series EDSC
- Number of Gangs 1
- Switch Type 2-Pole
- Amps 20 A
- Voltage 120 to 277V AC
- HP 1 hp @ 120V AC, 2 hp @ 240V AC
- Hub Style Feed-Thru
- Hub Size 1 in
- Mounting Mounting Holes/Hubs
- Legend Markings On/Off
- Special Features Corrosion Resistant, Pad Lockable in the On or Off Position
- NEMA Rating 7C, 7D, 9E, 9F, 9G
- Standards UL 1203, UL 894
- Safety Rating Class I, Division 1, Groups C, D; Class I, Division 2, Groups B, C, D; Class II, Division 1 & 2, Groups E, F, G; Class III
- Height 4 5/8 in
- Width 3 in
- Depth 4 11/16 in
- Body Material Malleable Iron
Manufacturer Details
- Manufacturer: Appleton Electric
- Condensed Mfg Number: EDSC110R2
- MPN: EDSC110-R2
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536509040
- GDS Category Name: Hazardous Location Tumbler Switches
- GDS Family Name: Switches
- GDS Segment Name: Electrical
- UNSPSC: 39121104
- UNSPSC Class ID: 11
- UNSPSC Commodity Name: Distribution and control centers and accessories
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Motor control centers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
