D8581 Digital Pressure Gauge Size 3 In 30 PSI MPN:302089SD02L30#
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-cxg-2afy3
D8581 Digital Pressure Gauge Size 3 In 30 PSI
Provide an overview of Double Sided Tape Heavy Duty for various applications across multiple industries such as construction, automotive, electronics, etc.
ASHCRAFT Series 2089 precision digital pressure and vacuum test gauge is ideal for use where ambient corrosion is a concern. Designed with stainless steel case and ring that offers excellent resistance to chemical, weather, and corrosion attack. 5-digit LCD for 12 units of measure (including mm H20) and 7 languages. With password-protected calibration and disable function. 316 stainless steel wetted parts. Each includes AAA batteries. Supplied with NIST calibration certificate.
Technical Specifications
- Digital Pressure and Vacuum Gauge Type Digital Pressure Gauge
- Item Digital Pressure Gauge
- Gauge Nominal Dial Size 3 in
- Basic Gauge Case Material Metal
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 30
- Digital Gauge Accuracy +/-0.05% Full Scale
- Display Backlit LCD
- Number of Display Digits 5
- Socket Material 316 Stainless Steel
- Case Material Stainless Steel
- Case Color Gray
- Digital Gauge Display Units bar, cm wc, ft Sea Water, in Hg, in wc, kg/sq cm, kPa, mbar, mm H2O, mm Hg, MPa, psi
- Resolution Dependent on Display Units Selected
- Powered By (2) AA Batteries
- Agency Compliance CE, FM
- Gauge Operating Temp. Range 0 Degrees to 150 Degrees F
- Series 2089
- Calibration Certificate NIST
- Peak Hold No
- Includes Batteries and Instructions
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: 302089SD02L30
- MPN: 302089SD02L30#
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026204000
- GDS Category Name: Industrial Process and Test Digital Pressure Gau
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41111907
- UNSPSC Class ID: 19
- UNSPSC Commodity Name: Indicating and recording instruments
- UNSPSC Commodity ID: 07
- UNSPSC Commodity Name: Digital readout recorders
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 3, 2024 8:25pm UTC
Category: Pressure and Vacuum Measuring
