D0803 Pressure Gauge 0 to 15 psi 4-1/2In 1/4In
The D0803 pressure gauge is an accurate instrument designed for measuring hydraulic and pneumatic pressures in a range from 0 to 15psi. It features a clear dial face with black markings for easy reading, along with a steel case and solid stem for durability. The threaded connections offer easy installation into machinery while the compact size makes it ideal for use in tight spaces. This gauge is perfect for mechanics, technicians or engineers looking to accurately measure pressure in their equipment or systems - making it an indispensable tool in various industrial settings.
This gauge features aluminum case construction to resist corrosion and impact in demanding applications.
Technical Specifications
- Item Pressure Gauge
- Gauge Application Test
- Gauge Nominal Dial Size 4 1/2 in
- Basic Gauge Case Material Aluminum
- Basic Gauge Wetted Parts Brass / Bronze
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 15
- Gauge Accuracy +/-0.25%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 0.05
- Gauge Case Material Epoxy Coated Aluminum
- Gauge Primary Range Numbered Graduations 1
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Bronze
- Gauge Sensor Material Phosphor Bronze
- Gauge Lens Material Glass
- Basic Gauge Lens Material Glass
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Calibration Certificate Included No
- Series 1082
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: 451082AS02L15
- MPN: 45-1082AS 02L 15
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Dial Test Pressure Gauges
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 3, 2024 8:26pm UTC
Category: Pressure and Vacuum Measuring
