D0992 Pressure Gauge 0 to 30 psi 2-1/2In 1/4In MPN:251009SW02LX6B30
Free Shipping
In Stock
A versatile pressure gauge manufactured by the renowned company D0992 offers the latest innovation with a large 2.5 inches diameter dial face, designed for easy reading of pressures that range from 0-30 psi displayed either in positive or negative signs making it ideal for those whose work involves accurate measurements under varying pressure levels whether at extreme low or high settings while providing safety features preventing any mishaps due to overpressure by giving prompt readings with its sturdy and reliable construction being perfect for industrial use hence ensuring smooth processes, cost-efficiency along with errorless information while meeting requirements of compressor operators, technicians and other laboratory professionals involved in chemically demanding sectors providing excellent performance under diverse situations.
Technical Specifications
- Item Pressure Gauge
- Gauge Application Oxygen Service Cleaned
- Gauge Nominal Dial Size 2 1/2 in
- Basic Gauge Case Material Stainless Steel
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 30
- Gauge Accuracy +/-1.00%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 0.5
- Gauge Case Material 304 Stainless Steel
- Gauge Case Color Stainless Steel
- Basic Gauge Socket Material Stainless Steel
- Gauge Socket Material 316 Stainless Steel
- Basic Gauge Sensor Material Stainless Steel
- Gauge Sensor Material 316 Stainless Steel
- Gauge Lens Material Polycarbonate
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Gauge Special Options PLUS!(TM) Performance
- Calibration Certificate Included No
- Series 1009
- Manufacturers Warranty Length 5 yr
Manufacturer Details
- Manufacturer: Ashcroft
- Condensed Mfg Number: 251009SW02LX6B30
- MPN: 251009SW02LX6B30
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Compressed Gas Dial Pressure Gauges
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
