Non-Spring Return Control Valve Actuator MPN:ARB24-SR

Non-Spring Return Control Valve Actuator has a 90° angle of rotation that is adjustable with mechanical stop. Running time of 90 seconds. For manual override, use the external push button.

Technical Specifications

• Item Non-Spring Return Control Valve Actuator
• Spring Return No
• Torque 180 in-lb
• Stroke Deg. 0 to 90
• Height 8 1/2 in
• Width 3 29/64 in
• Depth 2 31/64 in
• Signal Type Proportional
• Motor Direction CW or CCW
• Ambient Temp. Range -22 Degrees to 122 Degrees F
• Timing 90 sec
• Voltage 24V AC/DC
• Power Rating 2.5W

Manufacturer Details

• Manufacturer: Belimo
• Condensed Mfg Number: ARB24SR
• MPN: ARB24-SR

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: US
• CA Prop 65 Wht Label: N

Classification Details

• Harmonization Code: 8501104040
• GDS Category Name: Electric Actuators
• GDS Family Name: HVAC Controls and Thermostats
• GDS Segment Name: HVAC and Refrigeration
• UNSPSC: 31251501
• UNSPSC Class ID: 15
• UNSPSC Commodity Name: Actuators
• UNSPSC Commodity ID: 01
• UNSPSC Commodity Name: Electric actuators
• UNSPSC Family ID: 25
• UNSPSC Family Name: Pneumatic and hydraulic and electric control systems
• UNSPSC Segment ID: 31
• UNSPSC Segment Name: Manufacturing Components and Supplies

Shipping Details

• Not For Sale In: HI AK PR
