Cejn® Industrial Interchange Nipple 1/4" Body Size 1/8" Male NPT - Pkg Qty 10 10-310-5451
Cejn® Industrial Interchange Nipple 1/4" Body Size 1/8" Male NPT - Pkg Qty 10 10-310-5451
Series 310 Nipple - 1/8" Male NPT (Industrial Interchange 1/4")
Series 310 offers a wide range of easy-to-grip couplings, including Soft-Line and Streamline. Male threads on the couplings and nipples feature pre-applied thread sealant. The Series 310 vented safety version is disconnected in two stages in order to vent the coupling and minimize the risk of sudden component separation, which has the potential to cause operator injury. Full automatic operation ensures easy handling. The vented safety version complies with ISO Standard 4414 and EN 983.
Series 310 offers a wide range of easy-to-grip couplings, including Soft-Line and Streamline. Male threads on the couplings and nipples feature pre-applied thread sealant. The Series 310 vented safety version is disconnected in two stages in order to vent the coupling and minimize the risk of sudden component separation, which has the potential to cause operator injury. Full automatic operation ensures easy handling. The vented safety version complies with ISO Standard 4414 and EN 983.
- High Flow Capacity
- one-hand Operation
- Low Connection Force
Product Specifications
- BRANDCejn®
- MANUFACTURERS PART NUMBER10-310-5451
- CONSTRUCTIONHardened Zinc Plated Steel
- CFM32.7
- CONNECTION FORCE70.7 N
- NOMINAL FLOW DIAMETER7/32"
- MINIMUM BURST PRESSURE2030
- TEMPERATURE RANGE-4°F to +212°F
- CONNECTION CONFIGURATION1/8" Male NPT
- MAXIMUM OPERATING PSI232
Additional Information
- UNSPSC: 27131613
- Brand: Cejn Industrail Corp.
- Package Quantity: 10
- Country of Origin: SE
- FOB Origin: IL
- Ships by: PARCEL
- Comes in a kit: No
- Newly added to catalog: No
- Item is on Clearance: No
- Contains Hazardous Materials: No
- CA Proposition 65 Applies: Yes
- Package Weight: 0.25
Product info last updated on November 27, 2024 10:45pm UTC
Category: Hoses and Connectors
