Jobber Drill R HSS MPN:41788
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-CXG-10N939
Jobber Drill R HSS
Get the job done right with Jobber Drill R HSS from Chicago-Latrobe! These drill bits meet National Aerospace Specification (NAS) 907 Type B standards, ensuring top-notch quality and reliability. With a TiN coating, they are protected against wear and heat when drilling steel, stainless steel, and aluminum materials. The Jobber Length design provides versatility and ease-of-use for a wide range of applications. The R size delivers the perfect combination of precision and strength to meet your project needs. With its High Speed Steel material, this drill bit is durable enough to handle even the toughest jobs. Invest in Jobber Drill R HSS today and experience the difference in performance and efficiency!
Top product features:
- TiN coating for protection against wear and heat
- Jobber Length design for versatility and ease-of-use
- High Speed Steel material for durability
Top product applications:
- Drilling metal surfaces like steel, stainless steel, and aluminum
- Manufacturing and machining projects that require precise, reliable drilling
- Automotive repair and maintenance work when drilling into metal panels
These drill bits meet National Aerospace Specification (NAS) 907 Type B. They have a TiN coating that protects them from wear and heat when drilling steel, stainless steel, and aluminum.
Technical Specifications
- Item Jobber Length Drill Bit
- Drill Bit Size R
- Decimal Equivalent 0.3390
- Measurement System Letter
- Material - Machining High Speed Steel
- Finish - Machining TiN
- Drill Bit Point Angle 135 Degrees
- Drill Bit Point Type Split Point
- Coolant Fed Non-Coolant Through
- Flute Type Spiral
- Number of Flutes 2
- Flute Length 3 7/16 in
- Maximum Drilling Depth 1 5/16 in
- Helix Angle 28 Degrees
- Cutting Direction Right Hand
- Spiral Direction Right Hand
- Shank Type - Machining Straight
- Shank Dia. 21/64 in
- Shank Length 1 5/16 in
- Overall Length 4 3/4 in
- Depth:Dia. Ratio 4xD
- Drill Length Class Jobber Length
- Drill Point Length 0.0000 in
- Drill Bit Grouping Individual
- Series 150ASP-TN
- Standards NAS 907 Type B
- Aircraft Drill Yes
- Drill Diameter Tolerance +0.0000 in /-0.0010 in
- Primary Material Application Cast Iron, Stainless Steel, Steel
- Primary Material Application ISO Code K, M, P
Manufacturer Details
- Manufacturer: Chicago-Latrobe
- Condensed Mfg Number: 41788
- MPN: 41788
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Jobber Length Drill Bits
- GDS Family Name: Drilling and Holemaking
- GDS Segment Name: Machining
- UNSPSC: 27112801
- UNSPSC Class ID: 28
- UNSPSC Commodity Name: Tool attachments and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Drill bits
- UNSPSC Family ID: 11
- UNSPSC Family Name: Hand tools
- UNSPSC Segment ID: 27
- UNSPSC Segment Name: Tools and General Machinery
Shipping Details
- Not For Sale In: HI AK PR
Related ASINs: B0026GP4FM
Product info last updated on September 26, 2024 1:02pm UTC Category: Drilling and Holemaking
