Jobber Drill #21 HSS MPN:41691
Free Shipping
In Stock
Introducing Jobber Drill #21 HSS from Chicago-Latrobe - the perfect tool for all your drilling needs! Meeting National Aerospace Specification (NAS) 907 Type B standards, these high-speed steel (HSS) drill bits are designed to provide unmatched precision and durability when drilling stainless steel, aluminum, and other metal surfaces. With a #21 size and decimal equivalent of 0.1590, these jobber length drill bits offer excellent balance for a smooth, accurate performance. The TiN coating ensures maximum resistance to wear and heat, making it perfect for professional and DIY users alike. Whether you're a metalworker, engineer, or hobbyist, the Chicago-Latrobe Jobber Drill #21 HSS delivers superior quality, precision, and durability that won't let you down!
Top product features:
- Meets NAS 907 Type B standards
- TiN coating for heat and wear resistance
- Jobber length design
Top product applications:
- Drilling holes in steel, stainless steel, and aluminum
- Machining tasks on metal surfaces
- Manufacturing of machinery components
Technical Specifications
- Item Jobber Length Drill Bit
- Drill Bit Size #21
- Decimal Equivalent 0.1590
- Measurement System Wire
- Material - Machining High Speed Steel
- Finish - Machining TiN
- Drill Bit Point Angle 135 Degrees
- Drill Bit Point Type Split Point
- Coolant Fed Non-Coolant Through
- Flute Type Spiral
- Number of Flutes 2
- Flute Length 2 1/8 in
- Maximum Drilling Depth 5/8 in
- Helix Angle 28 Degrees
- Cutting Direction Right Hand
- Spiral Direction Right Hand
- Shank Type - Machining Straight
- Shank Dia. 5/32 in
- Shank Length 1 1/8 in
- Overall Length 3 1/4 in
- Depth:Dia. Ratio 4xD
- Drill Length Class Jobber Length
- Drill Point Length 0.0329 in
- Drill Bit Grouping Individual
- Series 150ASP-TN
- Standards NAS 907 Type B
- Aircraft Drill Yes
- Drill Diameter Tolerance +0.0000 in /-0.0007 in
- Primary Material Application Cast Iron, Stainless Steel, Steel
- Primary Material Application ISO Code K, M, P
Manufacturer Details
- Manufacturer: Chicago-Latrobe
- Condensed Mfg Number: 41691
- MPN: 41691
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8207504030
- GDS Category Name: Jobber Length Drill Bits
- GDS Family Name: Drilling and Holemaking
- GDS Segment Name: Machining
- UNSPSC: 27112801
- UNSPSC Class ID: 28
- UNSPSC Commodity Name: Tool attachments and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Drill bits
- UNSPSC Family ID: 11
- UNSPSC Family Name: Hand tools
- UNSPSC Segment ID: 27
- UNSPSC Segment Name: Tools and General Machinery
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on September 26, 2024 1:02pm UTC Category: Drilling and Holemaking
