Jobber Drill #39 HSS MPN:41709
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-CXG-10N986
Jobber Drill #39 HSS
Introducing our Jobber Drill #39 HSS from Chicago-Latrobe - the ultimate choice for your drilling needs! Made with high-speed steel, these bits are built to withstand even the toughest of materials including stainless steel, aluminum, and more. Their TiN coating provides excellent heat and wear resistance, ensuring that your bit stays sharp and lasts longer. Whether you're a professional contractor or a DIY enthusiast, these drill bits are perfect for a wide range of applications. With their precise measurements and quality craftsmanship, you can trust that every hole will be accurate and clean. So don't wait, upgrade your machining game today with Jobber Drill #39 HSS from Chicago-Latrobe!
Top product features:
- Made with high-speed steel for durability and strength
- TiN coating for heat and wear resistance
- Precise measurements for accurate and clean holes
Top product applications:
- Drilling into steel, stainless steel, and aluminum materials
- Machining metal components in industries such as aerospace, automotive, and manufacturing
- Use by professionals, hobbyists or DIY enthusiasts for drilling and machining tasks
These drill bits meet National Aerospace Specification (NAS) 907 Type B. They have a TiN coating that protects them from wear and heat when drilling steel, stainless steel, and aluminum.
Technical Specifications
- Item Jobber Length Drill Bit
- Drill Bit Size #39
- Decimal Equivalent 0.0995
- Measurement System Wire
- Material - Machining High Speed Steel
- Finish - Machining TiN
- Drill Bit Point Angle 135 Degrees
- Drill Bit Point Type Split Point
- Coolant Fed Non-Coolant Through
- Flute Type Spiral
- Number of Flutes 2
- Flute Length 1 3/8 in
- Maximum Drilling Depth 3/8 in
- Helix Angle 28 Degrees
- Cutting Direction Right Hand
- Spiral Direction Right Hand
- Shank Type - Machining Straight
- Shank Dia. 3/32 in
- Shank Length 1 in
- Overall Length 2 3/8 in
- Depth:Dia. Ratio 4xD
- Drill Length Class Jobber Length
- Drill Point Length 0.0206 in
- Drill Bit Grouping Individual
- Series 150ASP-TN
- Standards NAS 907 Type B
- Aircraft Drill Yes
- Drill Diameter Tolerance +0.0000 in /-0.0005 in
- Primary Material Application Cast Iron, Stainless Steel, Steel
- Primary Material Application ISO Code K, M, P
Manufacturer Details
- Manufacturer: Chicago-Latrobe
- Condensed Mfg Number: 41709
- MPN: 41709
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8207504030
- GDS Category Name: Jobber Length Drill Bits
- GDS Family Name: Drilling and Holemaking
- GDS Segment Name: Machining
- UNSPSC: 27112801
- UNSPSC Class ID: 28
- UNSPSC Commodity Name: Tool attachments and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Drill bits
- UNSPSC Family ID: 11
- UNSPSC Family Name: Hand tools
- UNSPSC Segment ID: 27
- UNSPSC Segment Name: Tools and General Machinery
Shipping Details
- Not For Sale In: HI AK PR
Related ASINs: B0026GOQIS
Product info last updated on September 26, 2024 1:02pm UTC Category: Drilling and Holemaking
