Screw Machine Drill #28 HSS MPN:48728
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-cxg-10u230
Screw Machine Drill #28 HSS
Introducing Screw Machine Drill Bit #28 HSS from Chicago-Latrobe, designed for precise and efficient drilling in various applications. With a bright finish and spiral flute design, these bits easily evacuate chips while maintaining a sharp edge even after multiple resharpenings. The high-speed steel material ensures durability and consistency, perfect for metal fabrication and electronics manufacturing. Its #28 decimal equivalent size makes it suitable for precise drilling tasks in various industries, offering benefits such as accuracy, speed, and cost-effectiveness. Invest in Screw Machine Drill Bit #28 HSS to improve your drilling operations today!
Top product features:
- Bright finish for long-lasting durability and sharp edges even after resharpenings.
- Spiral flute design for efficient chip evacuation during drilling process.
- High speed steel material for strength and consistency in various drilling applications.
Top product applications:
- Metal fabrication and assembly processes requiring precision drilling.
- Electronics manufacturing for drilling holes in printed circuit boards (PCBs).
- Machining workshops needing to create accurate hole patterns on various materials.
These drill bits have a bright finish that is not affected when the bits' cutting edges are resharpened. Spiral-flute drill bits evacuate chips as the bits drill into a workpiece.
Technical Specifications
- Item Screw Machine Drill Bit
- Drill Bit Size #28
- Decimal Equivalent 0.1405
- Measurement System Wire
- Material - Machining High Speed Steel
- Finish - Machining Bright (Uncoated)
- Drill Bit Point Angle 118 Degrees
- Drill Bit Point Type Conventional Point
- Flute Type Spiral
- Number of Flutes 2
- Flute Length 15/16 in
- Maximum Drilling Depth 15/16 in
- Helix Angle 28 Degrees
- Cutting Direction Right Hand
- Spiral Direction Right Hand
- Shank Type - Machining Straight
- Shank Dia. 1/8 in
- Shank Length 1 in
- Overall Length 1 15/16 in
- Depth:Dia. Ratio 4xD
- Drill Length Class Screw Machine Length
- Drill Point Length 0.0422 in
- Drill Bit Grouping Individual
- Series 157
- Standards Not Rated
- Drill Diameter Tolerance +0.0000 in /-0.0007 in
- Primary Material Application Aluminum, Brass, Bronze, Cast Iron, Copper, Steel
- Primary Material Application ISO Code K, N, P
Manufacturer Details
- Manufacturer: Chicago-Latrobe
- Condensed Mfg Number: 48728
- MPN: 48728
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8207502080
- GDS Category Name: Screw Machine Length Drill Bits
- GDS Family Name: Drilling and Holemaking
- GDS Segment Name: Machining
- UNSPSC: 27112801
- UNSPSC Class ID: 28
- UNSPSC Commodity Name: Tool attachments and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Drill bits
- UNSPSC Family ID: 11
- UNSPSC Family Name: Hand tools
- UNSPSC Segment ID: 27
- UNSPSC Segment Name: Tools and General Machinery
