Solid State Relay In 21 to 27VDC 20 MPN:EL100D10-24

This EL Series solid-state relay features a compact, panel-mount design, with high surge current ratings and low, off-state leakage current. It is housed in a compact, 21 wide x 35 mm long mini-puck package with polarized quick connect terminals.

Technical Specifications

• Item - Relay Solid State Relay
• Input or Control Voltage 21 to 27V DC
• Output or Controlled Voltage Range 3 to 100V DC
• Max. Output Amps w/Heat Sink 20
• Heat Sink Not Included
• Switch Type MOSFET
• Contact Form - Relay SPST-NO
• Input Power Consumption (Burden) 0.2W
• Mounting - Relay Surface
• Finger Safe No
• Body Height - Relay 0.56 in
• Body Width - Relay 0.83 in
• Body Depth - Relay 1.44 in
• Overall Height - Relay 1.0 in
• Max. Output Amps Without Heat Sink 9.0
• Case Color Black
• Standards CE, UL

Manufacturer Details

• Manufacturer: Crydom
• Condensed Mfg Number: EL100D1024
• MPN: EL100D10-24

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: MX
• CA Prop 65 Wht Label: Y
• CA Prop 65 Warning Msg Scenario: 7

Classification Details

• Harmonization Code: 8536490080
• GDS Category Name: Solid State Relays
• GDS Family Name: Relays
• GDS Segment Name: Electrical
• UNSPSC: 39121542
• UNSPSC Class ID: 15
• UNSPSC Commodity Name: Switches and controls and relays and accessories
• UNSPSC Commodity ID: 42
• UNSPSC Commodity Name: Solid state relays
• UNSPSC Family ID: 12
• UNSPSC Family Name: Electrical equipment and components and supplies
• UNSPSC Segment ID: 39
• UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

• Not For Sale In: HI AK PR
