Dual Solid State Relay In 4 to 15VDC 25 MPN:D2425D
Free Shipping
In Stock
The Dual Solid State Relay accepts input voltages ranging from 4 to 15VDC and offers a 5-amp load rating per relay channel enabling control of two separate circuits simultaneously with high performance accuracy making it ideal for diverse industries including but not limited to traffic management systems, solar inverters, UPS, elevator machines, medical equipment, etc. Each of its channels operates on an independent output and features both normally open (NO) and normally closed (NC) contacts with 5VDC maximum switching voltage, providing users with versatile configuration options when utilizing this relay for their application needs. Due to its durability under varying temperature conditions and robust design, this dual solid state relay is sure to meet the demands of customers who need a reliable solution for their control requirements.
Technical Specifications
- Item - Relay Dual Solid State Relay
- Input or Control Voltage 4 to 15V DC
- Output or Controlled Voltage Range 24 to 280V AC
- Max. Output Amps w/Heat Sink 25
- Heat Sink Not Included
- Switch Type SCR
- Contact Form - Relay (2) SPST-NO
- Relay Turns On At Zero Crossing
- Input Power Consumption (Burden) 0.1 to 0.6W
- Mounting - Relay Surface
- Finger Safe No
- Body Height - Relay 0.78 in
- Body Width - Relay 1.8 in
- Body Depth - Relay 2.3 in
- Overall Height - Relay 0.9 in
- Max. Output Amps Without Heat Sink 16.0
- Case Color Black
- Standards CE, CSA, UL, VDE
Manufacturer Details
- Manufacturer: Crydom
- Condensed Mfg Number: D2425D
- MPN: D2425D
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 8536490080
- GDS Category Name: Solid State Relays
- GDS Family Name: Relays
- GDS Segment Name: Electrical
- UNSPSC: 39121514
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Switches and controls and relays and accessories
- UNSPSC Commodity ID: 14
- UNSPSC Commodity Name: Power relays
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
