2 Bolt Flange Bearing Ball 1 3/16in Bore MPN:3FCV5
2 Bolt Flange Bearing Ball 1 3/16in Bore
Titan USA's solid carbide ball end mill with diameter of 0.2362 inches and length of cut (LOC) of 0.5118 inches is ideal for professional users in the aerospace, automotive, medical and mold making industries requiring precision and accuracy when machining intricate parts or designs. This versatile end mill offers increased efficiency and prolonged tool life with its four flutes, making it suitable for both roughing and finishing operations. With its solid carbide construction, Titan USA's ball end mill provides durability and heat resistance ensuring reliable performance in demanding applications.
Buy Dayton item #3FCV5 from our huge selection of Hardware Accessories to show your support for our ♻ Socially Responsible Veteran-Owned Business.
Technical Specifications
- Item 2-Bolt Flange Bearing
- Mounted Bearing Item 2-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 1 3/16 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Cast Iron
- Bearing Insert Material 52100 Chrome Steel
- Bolt Hole Center-to-Center 4 19/32 in
- Series Standard Duty
- Bolt Size 7/16 in
- Overall Height 1 37/64 in
- Overall Width 3 1/4 in
- Overall Length 5 9/16 in
- Bearing Lubrication Chevron SRI-2 or NLGI #2 Equivalent
- Dynamic Load Capacity 4,382 lb
- Static Load Capacity 2,517 lb
- Temp. Range -20 Degrees to 200 Degrees F
- Finish Painted
- Includes (2) Set Screws, Oiler Cap
- Dimension A 5 9/16 in
- Dimension B 3 1/4 in
- Dimension C 4 19/32 in
- Dimension D 1/2 in
- Dimension F 1 37/64 in
Manufacturer Details
- Manufacturer: Dayton
- Condensed Mfg Number: 3FCV5
- MPN: 3FCV5
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171504
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Ball bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
