2 Bolt Flange Bearing Ball 1 3/4in Bore MPN:3FCW2
2 Bolt Flange Bearing Ball 1 3/4in Bore
Titan USA's ball end mill is an ultra-precision machining tool ideal for micro and miniature machining applications. With a diameter of 0.0938 inches, a length of cut (LOC) at 0.2813 inches, and four flutes providing efficient heat reduction, this product offers superior accuracy, stability, and durability perfect for professional users in industries such as jewelry manufacturing, dental care, or electronics who require precise machining on small parts with high tolerances. This versatile ball end mill is designed to deliver smooth finishes, making it an essential tool for creating intricate details and sharp edges while maintaining strict precision and accuracy across various materials.
✓ Buy Dayton item #3FCW2 and get Free Shipping from our large selection of Hardware Accessories and show your support for Veteran-Owned Businesses.
Technical Specifications
- Item 2-Bolt Flange Bearing
- Mounted Bearing Item 2-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 1 3/4 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Cast Iron
- Bearing Insert Material 52100 Chrome Steel
- Bolt Hole Center-to-Center 5 27/32 in
- Series Standard Duty
- Bolt Size 9/16 in
- Overall Height 2 3/64 in
- Overall Width 4 3/8 in
- Overall Length 7 1/16 in
- Bearing Lubrication Chevron SRI-2 or NLGI #2 Equivalent
- Dynamic Load Capacity 7,157 lb
- Static Load Capacity 4,674 lb
- Temp. Range -20 Degrees to 200 Degrees F
- Finish Painted
- Includes (2) Set Screws, Oiler Cap
- Dimension A 7 in
- Dimension B 4 3/8 in
- Dimension C 5 27/32 in
- Dimension D 5/8 in
- Dimension F 2 3/64 in
Manufacturer Details
- Manufacturer: Dayton
- Condensed Mfg Number: 3FCW2
- MPN: 3FCW2
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171504
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Ball bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on June 10, 2023 12:37am UTC
Category: Bearings
