Air Swing Clamp: 67.44 lb Clamp Force, Left Hand Swing, 1.25" Stroke, Single Acting MPN:8416-LA
Air Swing Clamp: 67.44 lb Clamp Force, Left Hand Swing, 1.25" Stroke, Single Acting
Air Swing Clamp: 67.44 lb Clamp Force, Left Hand Swing, 1.25" Stroke, Single Acting 1/8 NPT Port, 1-3/4-12 Body Thread, 3.1693" Body Length, 130 Max psi
Product Information
- : 8416-LA
- Action Type: Single
- Body Diameter (Decimal Inch): 2.1299
- Body Diameter (mm): 54.10
- Body Length: 80.50
- Body Length (Decimal Inch): 3.1693
- Body Thread Size: 1-3/4-12
- Body Width/Diameter (Decimal Inch): 2.1299
- Body Width/Diameter (mm): 54.10
- Clamp Arm Compatibility: 821512 Standard Clamping Arm; 821554 T-Style Clamping Arm; 821555 T-Style Clamping Arm; 841512 Standard Clamping Arm
- Clamping Force (Lb.): 67.44
- Clamping Force (N): 300.00
- F -In--: 0.9800
- Features: Threaded Body Mounted in a Tapped Hole
- Includes: Clamping Arm; Spindle
- Maximum Operating Pressure (Psi): 130
- Minimum Operating Pressure (Bar): 3.00
- Mount Type: Threaded Body
- No Description: 2.1300
- Operating Volume (cc): 19.17 (Clamp); 23.27 (Unclamp)
- Operating Volume (Cu. In.): 1.1700 (Clamp); 1.4200 (Unclamp)
- Operation Type: Air
- Overall Open Length (Decimal Inch): 6.1400
- Port Size: 1/8 NPT
- Rod Diameter (Decimal Inch): 0.5000
- Rod Diameter (mm): 12.70
- Swing Direction: Left Hand
- Tapped Depth: 0.3800
- Total Stroke Distance (Decimal Inch): 1.2500
- Total Stroke Distance (mm): 31.75
- Vertical Stroke Distance (Decimal Inch): 0.5000
- Vertical Stroke Distance (Inch): 1/2
- Vertical Stroke Distance (mm): 12.70
Additional Information
- Hazardous Materials: No, oK to Ship Via Air
- Material Safety Data Sheet (MSDS) Required: No
- Country of Origin: US, United States
- TAA Compliant: Yes
- UNSPSC: 23153000
- CA Restricted (Prop 65): Unknown
- Package Weight: 1.50
- Prohibited States: AK,HI,PR
Product info last updated on October 1, 2024 12:25am UTC
Category: Swing Clamps and Arms
