CPVC Ball Valve Union Socket/FNPT 3/4 in MPN:163546343
This heavy-duty vinyl anti-fatigue mat spans 132 in length, providing extensive coverage for long work hours while standing with its generous 48 width to accommodate multiple users simultaneously; it's also 1 thick to minimize fatigue from prolonged usage. Designed with a beveled edge alleviating trip hazards, ensuring added safety in slippery or congested work environments such as factories or warehouses which require continuous attention while keeping the floor's cleanliness intact - hence suitable for use on flat surfaces including concrete floors. The product exhibits exceptional durability and resistant to oil, chemical spills, mild acids or salts thus maintaining its original appearance without damaging, deteriorating, or altering the color even after prolonged periods under harsh working conditions; hence suitable across diverse industries such as hospitals, automotive repair shops, food processing plants, chemical laboratories demanding high safety standards with long-lasting functionality and aesthetics.
Technical Specifications
- Item Ball Valve
- Body Material CPVC
- Body Style Inline True Union
- General Connection Type Socket
- Valve Structure 2-Piece
- Pipe Size 3/4 in
- Connection Type Socket/FNPT x Socket/FNPT
- Port Full
- Max. Pressure 150 psi CWP
- Max. Steam Pressure 0 psi WSP
- Temp. Range 32 Degrees to 176 Degrees F
- Ball Material CPVC
- Seat Material PTFE
- Stem Type Blowout Proof
- Handle Type Tee
- Handle Material Glass Filled Polypropylene
- Stem Material CPVC
- Body Seal Material EPDM
- Features Integrated Stainless Steel Mounting Inserts
- Ball Valve Product Group Manual
- Valve Basic Body Material Plastic
- Standards ASTM 1970-01, ASTM D1784, FDA, NSF 61, USP Class VI
- Overall Length 4.76 in
Manufacturer Details
- Manufacturer: GF
- Condensed Mfg Number: 163546343
- MPN: 163546343
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CH
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8481805090
- GDS Category Name: Ball Valves
- GDS Family Name: Shut-Off Valves
- GDS Segment Name: Plumbing
- UNSPSC: 40141607
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Valves
- UNSPSC Commodity ID: 07
- UNSPSC Commodity Name: Ball valves
- UNSPSC Family ID: 14
- UNSPSC Family Name: Fluid and gas distribution
- UNSPSC Segment ID: 40
- UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components
Shipping Details
- Not For Sale In: HI AK PR
