Pressure Sensor Range -0.7 to 14.5 psi MPN:PN2297

Technical Specifications

• Item Electronic Pressure Sensor
• Range -0.7 to 14.5 psi
• Analog Output 4 to 20mA or 0 to 10V DC
• Control Output PNP
• On/Off Setting Programmable
• Power Required 18 to 30V DC
• Process Connection 1/4 in NPT
• Electrical Connection 4 Pin M12
• Display 4 Digit LED
• Wetted Materials Stainless Steel
• Housing Material Stainless Steel
• Operating Temp. Range -13 Degrees to 176 Degrees F
• IP Rating 65/67
• Max. Pressure 450 psi
• Standards CE, CULus

Manufacturer Details

• Manufacturer: IFM
• Condensed Mfg Number: PN2297
• MPN: PN2297

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: DE
• CA Prop 65 Wht Label: N

Classification Details

• Harmonization Code: 9026204000
• GDS Category Name: Pressure Switch Transducer Combinations
• GDS Family Name: Switches
• GDS Segment Name: Electrical
• UNSPSC: 41111927
• UNSPSC Class ID: 19
• UNSPSC Commodity Name: Indicating and recording instruments
• UNSPSC Commodity ID: 27
• UNSPSC Commodity Name: Pressure sensors
• UNSPSC Family ID: 11
• UNSPSC Family Name: Measuring and observing and testing instruments
• UNSPSC Segment ID: 41
• UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment

Shipping Details

• Not For Sale In: HI AK PR
