Laydown Threading Insert: 16ER28UN IC1007, Solid Carbide MPN:3318601
Laydown Threading Insert: 16ER28UN IC1007, Solid Carbide MPN:3318601 is available to buy in increments of 1
Laydown Threading Insert: 16ER28UN IC1007, Solid Carbide
Laydown Threading Insert: 16ER28UN IC1007, Solid Carbide TiAlN Finish, Right Hand External UN Thread, 28 TPI, 9.52mm Inscribed Circle
Product Information
- : 3318601
- Coating Process: PVD
- Coating/Finish: TiAlN
- Corner Radius (Decimal Inch): 0.0040
- Corner Radius (mm): 0.11
- Inscribed Circle (Decimal Inch): 0.3750
- Inscribed Circle (Inch): 3/8
- Inscribed Circle (mm): 9.52
- Insert Hand: Right Hand
- Insert Material: Solid Carbide
- Insert Size Code: 16
- Insert Style: 16ER
- Iso Code: ISO 13399
- Manufacturer Grade: IC1007
- Material Grade: Submicron
- Pitch (mm): 28.00
- Primary Workpiece Material: Universal
- Primary Workpiece Material Code: H; K; M; N; P; S
- Series: ISCARTHREAD
- Standards: ISO 13399
- Thread Standard: UN
- Thread Type: External
- Threads Per Inch: 28
Additional Information
- Hazardous Materials: No, oK to Ship Via Air
- Material Safety Data Sheet (MSDS) Required: No
- Country of Origin: IL, Israel
- TAA Compliant: Yes
- UNSPSC: 23291804
- CA Restricted (Prop 65): Unknown
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 0.01
- Prohibited States: AK,HI,PR
Product info last updated on December 26, 2024 5:30am UTC
Category: Threading and Thread Mill Inserts
