Grooving Insert: GDM3020GM PR1225, Solid Carbide MPN:TKE10539
Grooving Insert: GDM3020GM PR1225, Solid Carbide MPN:TKE10539 is available to buy in increments of 10
Grooving Insert: GDM3020GM PR1225, Solid Carbide
Grooving Insert: GDM3020GM PR1225, Solid Carbide Megacoat, Neutral, 3 mm Cutting Width, 25.5 mm Max Depth, Series GD
Product Information
- : TKE10539
- Ansi Code: GDM3020N020GMPR1225
- Chip Breaker: GM
- Coating Process: PVD
- Coating/Finish: Megacoat
- Corner Radius (Decimal Inch): 0.0078
- Corner Radius (mm): 0.20
- Cutting Height (Decimal Inch): 0.1693
- Cutting Height (mm): 4.30
- Cutting Tool Application: Grooving
- Cutting Width (Decimal Inch): 0.1181
- Cutting Width (mm): 3.00
- Insert Hand: Neutral
- Insert Holding Method: Clamp
- Insert Material: Solid Carbide
- Insert Size: 3020
- Insert Size Code: 3020
- Insert Style: GDM
- Insert Thickness: 2.00
- Insert Thickness (Decimal Inch): 0.0906
- Iso Code: GDM3020N020GMPR1225
- Manufacturer Grade: PR1225
- Manufacturers Catalog Number: False
- Material Grade: Micrograin
- Maximum Depth of Cut (mm): 25.50
- Multi-Use Tool: Yes
- Overall Length (Decimal Inch): 0.7874
- Overall Length (mm): 20.00
- Primary Workpiece Material: Steel
- Primary Workpiece Material Code: P
- Rake: Positive
- Rake Angle: 2.00
- Secondary Workpiece Material: Stainless Steel
- Secondary Workpiece Material Code: M
- Series: GD
- Standards: ANSI; ISO
Additional Information
- Hazardous Materials: No, oK to Ship Via Air
- Material Safety Data Sheet (MSDS) Required: No
- Country of Origin: JP, Japan
- TAA Compliant: Yes
- UNSPSC: 23242105
- CA Restricted (Prop 65): Unknown
- Package Weight: 0.02
- Prohibited States: AK,HI,PR
Related ASINs: B0773N1ZFB, B0773PY2GB, B0773G4LL6
Product info last updated on October 1, 2024 2:26am UTC Category: Grooving Inserts
