Laydown Threading Insert: 16ER20UNTF PR1115, Solid Carbide MPN:TJY18882
Laydown Threading Insert: 16ER20UNTF PR1115, Solid Carbide MPN:TJY18882 is available to buy in increments of 5
Laydown Threading Insert: 16ER20UNTF PR1115, Solid Carbide
Laydown Threading Insert: 16ER20UNTF PR1115, Solid Carbide TiAlN Finish, Right Hand External UN Thread, 20 TPI, 9.53mm Inscribed Circle, 3.68mm Thick
Product Information
- : TJY18882
- Coating Process: PVD
- Coating/Finish: TiAlN
- Corner Radius (Decimal Inch): 0.0063
- Corner Radius (mm): 0.16
- Hole Diameter (Decimal Inch): 0.1575
- Hole Diameter (Mm) ( - 0 Decimals): 4.00
- Included Angle: 60
- Inscribed Circle (Decimal Inch): 0.3752
- Inscribed Circle (mm): 9.53
- Insert Hand: Right Hand
- Insert Material: Solid Carbide
- Insert Size Code: 16
- Insert Style: 16ER
- Iso Code: ISO 13485
- Manufacturer Grade: PR1115
- Primary Workpiece Material: Universal
- Primary Workpiece Material Code: K; M; N; P
- Series: TF
- Standards: FDA; ISO 13485
- Thickness (Decimal Inch - 4 Decimals): 0.1449
- Thickness (mm): 3.68
- Thread Standard: UN
- Thread Type: External
- Threads Per Inch: 20
Additional Information
- Hazardous Materials: No, oK to Ship Via Air
- Material Safety Data Sheet (MSDS) Required: No
- Country of Origin: CN, China
- TAA Compliant: No
- UNSPSC: 23291804
- CA Restricted (Prop 65): Unknown
- Package Weight: 0.05
- Prohibited States: AK,HI,PR
Product info last updated on July 1, 2024 12:53am UTC
Category: Threading and Thread Mill Inserts
