Fuse Block 0 to 30A CC 1 Pole MPN:L60030C1PQ

These fuse blocks are compatible with UL class CC fuses rated up to 30A, 600VAC for overcurrent protection of branch circuits, control circuits, lighting, transformers, and general loads. They are rejection-style blocks that prevent midget fuses from being installed.

UL Class and midget fuse blocks accept fuses sized and rated according to UL Class or midget specifications. They have an open top for access to fuses, clips or studs for securing fuses within the block, and terminals for connecting to the circuit. These fuse blocks are either bolted down or mounted on a DIN rail to hold them in place. They're commonly paired with fuse box covers to enclose the fuses and prevent accidental contact. They are nonindicating, so there's no visual signal when a fuse is blown.

Technical Specifications

• Item Fuse Block
• Fits Fuse Type Class CC
• Fuse UL Class CC
• Amp Range 0 to 30 A
• Number of Poles 1
• Voltage Rating 600V AC/DC
• For Fuse Size 1 1/2 in L x 13/32 in dia
• Compatible Fuse Series ATDR, ATMR, ATQR, CCMR, FNQ-R, KLDR, KLKR, KTK-R, LP-CC
• Series L600C
• Visual Indication Nonindicating
• Fuse Block Style Rejection
• Fuse Block Design Open
• Wire Range 14 to 10 AWG
• Mounting Style Bolt-Down
• Body Material Thermoplastic
• Connector Type Pressure Plate
• Height 1.25 in
• Width 0.78 in
• Length 3.0 in
• Spring Reinforced Clip No
• Features Clip Design Reduces Resistant and Heat, Spacing Saving Design
• Standards CSA Certified, RoHS, UL Listed

Manufacturer Details

• Manufacturer: Littelfuse
• Condensed Mfg Number: L60030C1PQ
• MPN: L60030C1PQ

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: CN
• CA Prop 65 Wht Label: Y
• CA Prop 65 Cancer Warning: Lead
• CA Prop 65 Repro Warning: Lead
• CA Prop 65 Warning Msg Scenario: 4

Classification Details

• Harmonization Code: 8536904000
• GDS Category Name: Fuse Blocks
• GDS Family Name: Fuses
• GDS Segment Name: Electrical
• UNSPSC: 39121411
• UNSPSC Class ID: 14
• UNSPSC Commodity Name: Lugs connectors and terminals
• UNSPSC Commodity ID: 11
• UNSPSC Commodity Name: Fuse blocks
• UNSPSC Family ID: 12
• UNSPSC Family Name: Electrical equipment and components and supplies
• UNSPSC Segment ID: 39
• UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

• Not For Sale In: HI AK PR
