H7803 Time Delay Rlay 24VAC/DC 10A DPDT 3 sec. MPN:TR-51628-12
Macromatics H7803 Time Delay Relay is an excellent choice for anyone looking for a reliable and versatile timing relay solution for their electrical projects. With an adjustable timing range of 3-300 seconds, 24V AC/DC input voltage, and 10A DPDT output contacts, this timer delay relay is perfect for applications such as controlling motors, fans, pumps, or other appliances with adjustable delay timings. The single function timing relay features an off delay feature that automatically turns the device on after a set period of time, making it highly energy-efficient and cost-effective. Whether you're working in automation, manufacturing, or HVAC, this Macromatic Time Delay Relay is a must-have tool for your electrical system. Its easy installation, adjustable timing range, and high durability make it an ideal choice for any project that requires precise control of electrical devices.
Top product features:
- Adjustable timing range of 3-300 seconds: Allows for precise control over delay timings
- Single Function Timing Relay: Provides a reliable and versatile timing solution for various applications
- 10A DPDT output contacts: Enables the operation of multiple devices with high current capacity
Top product applications:
- Controlling motors, pumps, and other appliances with variable speeds and time delays in manufacturing environments
- Powering on/off lamps, lights, and other electrical devices at specified intervals to reduce energy consumption
- Turning on security systems, alarms, and surveillance equipment after a certain period of absence or inactivity.
Technical Specifications
- Item - Relay Single Function Timing Relay
- Function - Timing Relay Off Delay
- Coil Volts 24V AC/DC
- AC Contact Rating - Relay 10A @ 240V
- DC Contact Rating - Relay 10A @ 30V
- Base Type - Plug In Relay Octal
- Number of Pins - Relay 11
- Mounting - Relay Plug In
- Contact Form - Relay DPDT
- Power Consumption - Relay 2.0 VA
- Adjustment Method - Timer Potentiometer
- Min. Time Setting - Timer 3.0 sec
- Max. Time Setting - Timer 5 min
- Status Indicator None
- Contact Material Silver Nickel
- Body Height - Relay 2.9 in
- Body Width - Relay 2.4 in
- Body Depth - Relay 1.7 in
- Overall Height - Relay 3.1 in
- Electrical Connection Socket
- Socket 1EGP2, 1EGP4, 6X156
- Hz - Electrical 50 Hz, 60 Hz
- Standards CE, CSA, UR
