H7804 Time Delay Rlay 24VAC/DC 10A DPDT 9 sec. MPN:TR-51628-14
The Macromatic H7804 Time Delay Relay is the perfect solution for controlling electrical devices with delayed power-off. With an adjustable timing range of 9 to 900 seconds and a rating of 10A, this relay offers reliable performance in various applications. Featuring 24V AC/DC input voltage, DPDT output contacts, and an 11 pin octal socket, the H7804 ensures seamless integration into your electrical system. Its off delay function allows you to set a specified time for the load to remain on after the power is turned off, providing convenient control over your devices. The Macromatic H7804 Time Delay Relay can be used in numerous applications such as heating and ventilation systems, lighting fixtures, motors, pumps, and more. Its durable construction and cost-effective design make it an ideal choice for commercial, industrial, and residential settings. Invest in the Macromatic H7804 Time Delay Relay today and enjoy the benefits of reliable and efficient power control.
Top product features:
- Off Delay Function: Provides convenient control over electrical devices by allowing users to set a specified time for the load to remain on after power is turned off.
- Adjustable Timing Range: Enables users to customize the timing of the delay according to their needs, ranging from 9 seconds up to 900 seconds.
- DPDT Output Contacts: Allows for the control of two separate loads with a single relay, providing cost-effective and efficient power management.
Top product applications:
- HVAC Systems: The Macromatic H7804 Time Delay Relay can be used to control heating or cooling systems in commercial and residential buildings. It allows for a programmed delay after the system is turned off, ensuring that the room reaches the desired temperature before shutting down.
- Lighting Control: The relay can be utilized to control lighting fixtures, such as floodlights or outdoor lights, by automatically turning them off after a predetermined time has passed. This can save energy and reduce costs associated with unnecessary lighting.
- Industrial Machinery: The H7804 Time Delay Relay can be used to control the power supply of industrial machinery or equipment that requires a cool-down period after use. It ensures that the machine is safely turned off after a delay, preventing damage or overheating.
Technical Specifications
- Item - Relay Single Function Timing Relay
- Function - Timing Relay Off Delay
- Coil Volts 24V AC/DC
- AC Contact Rating - Relay 10A @ 240V
- DC Contact Rating - Relay 10A @ 30V
- Base Type - Plug In Relay Octal
- Number of Pins - Relay 11
- Mounting - Relay Plug In
- Contact Form - Relay DPDT
- Power Consumption - Relay 2.0 VA
- Adjustment Method - Timer Potentiometer
- Min. Time Setting - Timer 9.0 sec
- Max. Time Setting - Timer 15 min
- Status Indicator None
- Contact Material Silver Nickel
- Body Height - Relay 2.9 in
- Body Width - Relay 2.4 in
- Body Depth - Relay 1.7 in
- Overall Height - Relay 3.1 in
- Electrical Connection Socket
- Socket 1EGP2, 1EGP4, 6X156
- Hz - Electrical 50 Hz, 60 Hz
- Standards CE, CSA, UR
