H7836 Time Delay Relay 24VAC/DC 10A DPDT MPN:TR-55128-08

Discount: See in Cart
Free Shipping
In Stock
Brand: Macromatic
Part #: TR-55128-08
SKU
226-CXG-23NV21
H7836 Time Delay Relay 24VAC/DC 10A DPDT
Macromatic’s Time Delay Relay features a Repeat Cycle (ON 1st) function with an adjustable timing range of 0.6-60 seconds, 24V AC/DC input voltage and 10A DPDT output contacts, utilizing an 8 pin octal socket.

Technical Specifications

  • Item - Relay Single Function Timing Relay
  • Function - Timing Relay Repeat Cycle (On First)
  • Coil Volts 24V AC/DC
  • AC Contact Rating - Relay 10A @ 240V
  • DC Contact Rating - Relay 10A @ 30V
  • Base Type - Plug In Relay Octal
  • Number of Pins - Relay 8
  • Mounting - Relay Plug In
  • Contact Form - Relay DPDT
  • Power Consumption - Relay 2.0 VA
  • Adjustment Method - Timer Potentiometer
  • Min. Time Setting - Timer 0.6 sec
  • Max. Time Setting - Timer 1 min
  • Status Indicator None
  • Contact Material Silver Nickel
  • Body Height - Relay 2.9 in
  • Body Width - Relay 2.4 in
  • Body Depth - Relay 1.7 in
  • Overall Height - Relay 3.1 in
  • Electrical Connection Socket
  • Socket 1EGP3, 1EGP5, 5X852
  • Hz - Electrical 50 Hz, 60 Hz
  • Standards CE, CSA, UR

Manufacturer Details

  • Manufacturer: Macromatic
  • Condensed Mfg Number: TR5512808
  • MPN: TR-55128-08

Label Details

  • Hazardous Material: N
  • Green Material Flag: N
  • Country of Origin: US
  • CA Prop 65 Wht Label: N

Classification Details

  • Harmonization Code: 8536490075
  • GDS Category Name: Time-Delay Relays
  • GDS Family Name: Relays
  • GDS Segment Name: Electrical
  • UNSPSC: 39121519
  • UNSPSC Class ID: 15
  • UNSPSC Commodity Name: Switches and controls and relays and accessories
  • UNSPSC Commodity ID: 19
  • UNSPSC Commodity Name: Time relays
  • UNSPSC Family ID: 12
  • UNSPSC Family Name: Electrical equipment and components and supplies
  • UNSPSC Segment ID: 39
  • UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

  • Not For Sale In: HI AK PR
