Control Relay Dual Pump Down 120V MPN:LCP2D100

Discount: See in Cart
Free Shipping
In Stock
Brand: Macromatic
Part #: LCP2D100
SKU
226-CXG-31EL63
Control Relay Dual Pump Down 120V

Macromatic's LCP Series Liquid Level Control Relay is designed for single probe pump down applications in conductive liquid environments. This versatile relay detects liquid levels by comparing the resistance between probes with an adjustable setpoint. The output controls pumps, solenoids, or valves to maintain, raise, or lower liquid levels in tanks. Probes are protected from electroplating issues with DC voltage pulsing. With a compact and plug-in design, this relay is ideal for various applications including HVAC and refrigeration systems, sump pumps, water treatment plants, and more. Its simple user interface and adjustable setpoint make it a cost-effective solution for precise liquid level control in industrial settings.

Top product features:

  • Compact and plug-in design for easy installation
  • Adjustable setpoint for precise liquid level control
  • Protected probes with DC voltage pulsing to prevent electroplating

Top product applications:

  • Sump pump systems in residential and commercial buildings
  • Irrigation systems in agriculture and landscaping
  • Chemical mixing tanks in chemical and pharmaceutical industries
Macromatic's LCP Series Liquid Level Control Relay detects and controls levels of conductive liquids (tap water, seawater, sewage, chemical solutions, coffee, ice cream, etc.) in single probe pump up or pump down applications. The conductive properties of the liquid complete a circuit between a probe and common when the liquid comes in contact with both. This relay compares the value of the measured resistance between probes with the setpoint of the adjustable potentiometer provided on the product. The output of the relay is used to control pumps, solenoids, or valves to lower, raise, or maintain the level of the liquid in the tank. Probes are pulsed with a DC voltage to prevent potential electroplating issues. A built-in time delay prevents rapid cycling.

Technical Specifications

  • Item Level Control Relay
  • Type Plug-In
  • Control Type Liquid Level Dual Probe Pump Down
  • Switch Type Single Pole Double Throw
  • Enclosure Height (In.) 3 1/5 in
  • Enclosure Width (In.) 1 7/10 in
  • Enclosure Depth (In.) 2 4/5 in
  • Enclosure Color White
  • Input Voltage 120V AC
  • Special Features 10A Relay Output, 5V DC Pulsed Probe Voltage, Adjustable Sensitivity, LED Indication
  • Special Information 8 Pin Octal Socket Required, Galvanically Isolated
  • Application Level Control Relay
  • Agency Compliance cURus

Manufacturer Details

  • Manufacturer: Macromatic
  • Condensed Mfg Number: LCP2D100
  • MPN: LCP2D100

Label Details

  • Hazardous Material: N
  • Green Material Flag: N
  • Country of Origin: US
  • CA Prop 65 Wht Label: N

Classification Details

  • Harmonization Code: 8536490075
  • GDS Category Name: Water Level Controls
  • GDS Family Name: HVAC Controls and Thermostats
  • GDS Segment Name: HVAC and Refrigeration
  • UNSPSC: 39121535
  • UNSPSC Class ID: 15
  • UNSPSC Commodity Name: Switches and controls and relays and accessories
  • UNSPSC Commodity ID: 35
  • UNSPSC Commodity Name: Control relays
  • UNSPSC Family ID: 12
  • UNSPSC Family Name: Electrical equipment and components and supplies
  • UNSPSC Segment ID: 39
  • UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

  • Not For Sale In: HI AK PR
