Time Delay Relay 100 hr Max Time Setting MPN:TR-6132U

Technical Specifications

• Item - Relay Single Function Timing Relay
• Function - Timing Relay Watchdog (Retriggerable One Shot)
• Coil Volts 24 to 240V AC,12 to 125V DC
• AC Contact Rating - Relay 10A @ 240V
• DC Contact Rating - Relay 10A @ 30V
• Base Type - Plug In Relay Octal
• Number of Pins - Relay 11
• Mounting - Relay Plug In
• Contact Form - Relay DPDT
• Power Consumption - Relay 1.5 W, 2.0 VA
• Adjustment Method - Timer Potentiometer
• Min. Time Setting - Timer 0.05 sec
• Max. Time Setting - Timer 4 day 4 hr
• Status Indicator None
• Contact Material Silver Nickel
• Body Height - Relay 2.9 in
• Body Width - Relay 2.4 in
• Body Depth - Relay 1.7 in
• Overall Height - Relay 3.1 in
• Electrical Connection Socket
• Socket 20XG08, 5B585, 6CVD7, 6X156
• Hz - Electrical 50 Hz, 60 Hz
• Standards CE, cURus

Manufacturer Details

• Manufacturer: Macromatic
• Condensed Mfg Number: TR6132U
• MPN: TR-6132U

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: US
• CA Prop 65 Wht Label: N

Classification Details

• Harmonization Code: 8536490075
• GDS Category Name: Time-Delay Relays
• GDS Family Name: Relays
• GDS Segment Name: Electrical
• UNSPSC: 39121519
• UNSPSC Class ID: 15
• UNSPSC Commodity Name: Switches and controls and relays and accessories
• UNSPSC Commodity ID: 19
• UNSPSC Commodity Name: Time relays
• UNSPSC Family ID: 12
• UNSPSC Family Name: Electrical equipment and components and supplies
• UNSPSC Segment ID: 39
• UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

• Not For Sale In: HI AK PR
