Phase Monitor Relay 208VAC Plug SPDT MPN:PAP208

Discount: See in Cart
Free Shipping
In Stock
Brand: Macromatic
Part #: PAP208
SKU
226-CXG-5WMJ4
Phase Monitor Relay 208VAC Plug SPDT
Macromatic's PAP Series Three-Phase Monitor Relay continuously monitors all voltages of a 208V three-phase system. It is used to protect motors and equipment from expensive damage due to phase loss, phase reversal, and undervoltage. This product detects single phasing and unbalanced voltages regardless of regenerative voltages. Unlike similar three-phase monitor relays, this relay will continue to function even with a lost phase. It is the only line-powered unit in its class to retain fault indication and continuous monitoring of all voltages during a phase loss, increasing the ease of troubleshooting and the level of protection.

Technical Specifications

  • Item - Relay Phase Monitor Relay
  • Input or Control Voltage 208V AC
  • AC Contact Rating - Relay 10A @ 277V
  • DC Contact Rating - Relay 7A @ 30V
  • Base Type - Plug In Relay Octal
  • Number of Pins - Relay 8
  • Mounting - Relay Plug In
  • Contact Form - Relay SPDT
  • Over Voltage No
  • Under Voltage 156 to 198V AC
  • Phase Loss Sensitivity Yes
  • Phase Loss Time Delay Fixed 0.1 sec
  • Phase Reversal Yes
  • Phase Reversal Time Delay Fixed 0.1 sec
  • Phase Unbalance No
  • Restart Auto
  • Restart Time Delay Fixed 1.0 sec
  • Socket Code - Relay A
  • Body Height - Relay 2.9 in
  • Body Width - Relay 1.7 in
  • Body Depth - Relay 2.4 in
  • Overall Height - Relay 3.5 in

Manufacturer Details

  • Manufacturer: Macromatic
  • Condensed Mfg Number: PAP208
  • MPN: PAP208

Label Details

  • Hazardous Material: N
  • Green Material Flag: N
  • Country of Origin: US
  • CA Prop 65 Wht Label: N

Classification Details

  • Harmonization Code: 8536490080
  • GDS Category Name: Phase Monitoring Relays
  • GDS Family Name: Relays
  • GDS Segment Name: Electrical
  • UNSPSC: 39121517
  • UNSPSC Class ID: 15
  • UNSPSC Commodity Name: Switches and controls and relays and accessories
  • UNSPSC Commodity ID: 17
  • UNSPSC Commodity Name: Alternating voltage relays
  • UNSPSC Family ID: 12
  • UNSPSC Family Name: Electrical equipment and components and supplies
  • UNSPSC Segment ID: 39
  • UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

  • Not For Sale In: HI AK PR
