Piano Hinge 7 ft L 1-11/16 in W MPN:FS302-001-630
A durable plastic rod made of acetal material, available in white color, with dimensions of 5/8 inch diameter and 10 feet length can be utilized across numerous industries where high strength, toughness, rigidity, low friction coefficient and resistance to moisture or chemicals are required. These properties make this rod suitable for various applications such as bearing balls or bushings replacement in mechanic systems, gears, machinery components or housings on engines where wear-resistance or precision movement are crucial aspects of their functioning. Acetal material's high resistance to dimensional stability combined with excellent mechanical strength and low thermal expansion coefficient allow this rod to be used without concerns of cracking or deformation under heavy pressure or temperature changes when placed inside bearings, slides or guides in vehicles, machinery, appliances, robotics or military equipment among other industries where its superior properties become fundamental. With a smooth finish and easy machining this rod provides engineers and manufacturers with an accurate, versatile component for producing reliable components which operate safely under extreme conditions while reducing maintenance costs.
Technical Specifications
- Item Continuous Hinge
- Ligature Resistant No
- Material Stainless Steel
- Range of Motion 90 Degrees
- Finish Satin
- Holes With
- Load Capacity 600.0 lb
- Orientation Non Handed
- Overall Knuckle Height 1 in
- Door Leaf Height 84 in
- Frame Leaf Height 84 in
- Door Leaf Width 1 11/16 in
- Frame Leaf Width 1 11/16 in
- Door Leaf Thickness 0.438 in
- Frame Leaf Thickness 0.438 in
- Required Door Thickness 1-3/4 in
- Length 7 ft
- Hardware Included
- Holes per Leaf 2
- Mounting Full Surface
- Pin Dia. 1/4 in
- Pin Material 304 Stainless Steel
- Pin Type Nonremovable
- Standards ANSI/BHMA Standard A156.26 Grade 1
- Overall Width 3 3/4 in
Manufacturer Details
- Manufacturer: Markar
- Condensed Mfg Number: FS302001630
- MPN: FS302-001-630
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8302106030
- GDS Category Name: Piano Hinges
- GDS Family Name: Latches Hasps and Hinges
- GDS Segment Name: Hardware
- UNSPSC: 31162403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Miscellaneous fasteners
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Hinges
- UNSPSC Family ID: 16
- UNSPSC Family Name: Hardware
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
