Limiter Fuse CNL Series 275A 80VDC MPN:CNL275

Time-delay, indicating forklift fuses tolerate temporary inrush currents without opening, which prevents nuisance-blowing from motor and equipment startups. Also called slow-blow forklift fuses, these series ANL and CNL fuses open to disconnect an electrical circuit when exposed to sustained loads and short circuits. They have a see-through window that reveals whether the fuse wire is intact or has melted.

Forklift fuses provide overcurrent protection for heavy-duty loads in lift trucks, scissor lifts, pallet movers, and other DC battery-powered equipment. They have dual AC/DC voltage ratings and are rated for higher voltages than other automotive fuses. These fuses bolt onto their mountings for a secure hold that resists loosening from vibration and helps ensure proper seating to maintain contact with the circuit. They have either a cylindrical body for standard installations or a flat body for use where installation space is limited.

Technical Specifications

• Item Forklift Limiter Fuse
• Amps 275 A
• AC Voltage Rating 80V AC
• DC Voltage Rating 80V DC
• Series CNL
• Visual Indication Indicating
• Speed Time Delay
• Body Style Bolt-On
• Fits Fuse Block Style Nonrejection
• Interrupt Rating 2.5kA at 80V AC, 2.5kA at 80V DC
• Fuse Size 3-3/16 in L x 3/4 in W x 13/32 in D
• Length 3 3/16 in
• Width 3/4 in
• Depth 13/32 in
• Diameter Not Applicable
• Equivalent Brand and Series Bussmann ANL, Littelfuse CNL, Mersen CNL
• Equivalent Series ANL, CNL
• Body Material Fiberglass
• Element Single
• Standards UL Recognized Component To Standard 248-1, File E60314 JFHR2

Manufacturer Details

• Manufacturer: Mersen
• Condensed Mfg Number: CNL275
• MPN: CNL275

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: CN
• CA Prop 65 Wht Label: N

Classification Details

• Harmonization Code: 8536100040
• GDS Category Name: Forklift Limiter Fuses
• GDS Family Name: Fuses
• GDS Segment Name: Electrical
• UNSPSC: 39121604
• UNSPSC Class ID: 16
• UNSPSC Commodity Name: Circuit protection devices and accessories
• UNSPSC Commodity ID: 04
• UNSPSC Commodity Name: Time delay fuses
• UNSPSC Family ID: 12
• UNSPSC Family Name: Electrical equipment and components and supplies
• UNSPSC Segment ID: 39
• UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

• Not For Sale In: HI AK PR
