K4590 Pressure Gauge 0 to 20 In H2O MPN:142-SA-00-O(AA)-20H

Technical Specifications

• Differential Pressure Gauge Type Differential Pressure Gauge
• Item Differential Pressure Gauge
• Gauge Nominal Dial Size 2 1/2 in
• Basic Gauge Case Material Metal
• Basic Gauge Wetted Parts Stainless Steel / Buna-N
• Differential Gauge Connection Type FNPT
• Differential Gauge Connection Size 1/4 in
• Gauge Connection Location Back
• Differential Pressure Range Units in wc
• Differential Pressure Range Value 0 to 20
• Gauge Accuracy +/-3-2-3%
• Body Material 316 Stainless Steel
• Gauge Primary Range Smallest Graduation 1
• Diaphragm Material Buna-N
• Piston Material Stainless Steel
• Seal Material Buna-N
• Gauge Operating Temp. Range -40 Degrees to 200 Degrees F
• Rated Total Pressure 3000 psi
• Relay Type SPDT
• Contact Rating 0.25A, 125V AC/V DC
• Dial Material Engineered Plastic
• Standards ASME B1.20.1, ASME B40.100, CSA-C22.2 No. 14.25 and 30, EN-61010-1, NACE MR0175, NEMA Std. No. 250, SAE J514, UL Std. No. 50, 508 and 1203
• Scale Type Pressure
• Includes Installation and Operation Manual
• Manufacturers Warranty Length 5 yr

Manufacturer Details

• Manufacturer: Midwest
• Condensed Mfg Number: 142SA00OAA20H
• MPN: 142-SA-00-O(AA)-20H

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: US
• CA Prop 65 Wht Label: N

Classification Details

• Harmonization Code: 9026208000
• GDS Category Name: Dial Differential Pressure Gauges with Switch
• GDS Family Name: Pressure and Vacuum Measuring
• GDS Segment Name: Test Instruments
• UNSPSC: 41112403
• UNSPSC Class ID: 24
• UNSPSC Commodity Name: Pressure measuring and control instruments
• UNSPSC Commodity ID: 03
• UNSPSC Commodity Name: Pressure indicators
• UNSPSC Family ID: 11
• UNSPSC Family Name: Measuring and observing and testing instruments
• UNSPSC Segment ID: 41
• UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment

Shipping Details

• Not For Sale In: HI AK PR
