Y Strainer 8 3/8 H 0.062 Perf Cast Iron MPN:3 758 N Iron Body
Free Shipping
In Stock
Keep your steam systems clean and protected with the MUELLER STEAM SPECIALTY Y strainer! This reliable cast iron strainer is designed to protect meters, pumps, and valves from contaminants such as dirt, scale, and rust. Its bosses at the inlet and outlet flanges provide easy installation of gauge taps, while the recessed seat in the cover ensures accurate screen alignment. The open area ratio is greater than the pipe size, which minimizes pressure drop for improved efficiency. Ideal for use in a variety of industries including heating, plumbing, and mechanical systems, this strainer will help maintain the integrity and performance of your steam system. Upgrade to MUELLER STEAM SPECIALTY Y strainer for peace of mind and unbeatable protection!
Top product features:
- Bosses at the inlet and outlet flanges for easy installation of gauge taps
- Open area ratio greater than the pipe size to minimize pressure drop
- Recessed seat in the cover for accurate screen alignment
Top product applications:
- Protection for meters, pumps, and valves in steam systems from contaminants such as dirt, scale, and rust
- Use in heating, plumbing, and mechanical systems that require low pressure drop
- Optimal performance at 125 psi @ 450 Degrees F WSP and 200 psi @ 150 Degrees F WOG
Technical Specifications
- Item Y Strainer
- Pipe Size 3 in
- Connection Type Flanged
- Housing Material Cast Iron
- Max. Pressure 125 psi @ 450 Degrees F WSP, 200 psi @ 150 Degrees F WOG
- Length 10 1/8 in
- Screen Area 0.06 sq in
- Screen Material 304 Stainless Steel
- Mesh 31/500 in
- Max. Fluid Temp. 150 Degrees F
- Blow-off Port 1 in
- Class 125
Manufacturer Details
- Manufacturer: Mueller
- Condensed Mfg Number: 3758NIronBody
- MPN: 3 758 N Iron Body
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8421290065
- GDS Category Name: Y Strainers
- GDS Family Name: Filtration
- GDS Segment Name: Plumbing
- UNSPSC: 40142501
- UNSPSC Class ID: 25
- UNSPSC Commodity Name: Traps and strainers
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Liquid strainers
- UNSPSC Family ID: 14
- UNSPSC Family Name: Fluid and gas distribution
- UNSPSC Segment ID: 40
- UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components
Shipping Details
- Not For Sale In: HI AK PR
