Extension Tap #10-24 HSS MPN:15258

The bright finish on these taps provides a smooth, polished surface. High-speed steel taps provide good wear resistance in general purpose tapping applications in a range of materials. Spiral-point taps have straight flutes with a spiral point that pushes chips in front of the tap as it moves into a hole and out the other side, eventually forcing the chips out of the hole. They are used for threading through holes.

Technical Specifications

• Item Extension Tap
• Thread Size #10-24
• Thread Standard UNC
• Tap Finish Bright (Uncoated)
• Overall Length 6 in
• Thread Length 7/8 in
• 75% Thread Drill Size #25
• Thread Limit H3
• Class of Fit 3B
• Thread Direction Right Hand
• Number of Flutes 2
• 55% Thread Drill Size #21
• 65% Thread Drill Size #23
• Extended Neck Yes
• Extended Shank Yes
• Spiral Direction Neutral
• Material Grade - Machining Common Special
• Measurement System Pipe
• Series Common Special
• Shank Dia. 3/16 in
• Shank Length 5 7/64 in
• Square Size 0.1520 in
• Standards ANSI
• Tap Chamfer Plug
• Tap Grouping Individual
• Tap Length Standard ANSI
• Tap Material High Speed Steel
• Tap Shank Standard ANSI
• Tap Style Extension
• Tap Thread Size #10-24
• Tap Type Spiral Point
• Threads per Inch 24 TPI

Manufacturer Details

• Manufacturer: GoVets Direct
• Condensed Mfg Number: 15258
• MPN: 15258

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: US
• CA Prop 65 Wht Label: N

Classification Details

• GDS Category Name: Extension Taps
• GDS Family Name: Threading
• GDS Segment Name: Machining
• UNSPSC: 23153305
• UNSPSC Class ID: 33
• UNSPSC Commodity Name: Cutting tools
• UNSPSC Commodity ID: 05
• UNSPSC Commodity Name: Taps or dies
• UNSPSC Family ID: 15
• UNSPSC Family Name: Industrial process machinery and equipment and supplies
• UNSPSC Segment ID: 23
• UNSPSC Segment Name: Industrial Manufacturing and Processing Machinery and Accessories

Shipping Details

• Not For Sale In: HI AK PR
