Pillow Block Brg 1 3/16 in Bore Polymer MPN:SUCPPL206-19
Pillow Block Brg 1 3/16 in Bore Polymer
The compression spring with an outside diameter of 2.35 inches and free length of 4.5 inches is a versatile option suited for diverse applications where forces such as tension or pressure need to be exerted, released or regulated. This precision-engineered component made from carbon steel exhibits high reliability and durability in function. Commonly used in spring-based products like tool returns, suspensions or locks, its usage across various industries include automotive, hardware, machinery or consumer goods manufacturing.
Get NTN item #SUCPPL206-19 from our selection of Hardware Accessories while supporting Veterans 🎖.
Technical Specifications
- Item Pillow Block Bearing
- Mounted Bearing Item Pillow Block Bearing
- Bearing Insert Type Ball
- Bore Dia. 1 3/16 in
- Bolt Hole Center-to-Center 119 mm
- Mounting Surface to Shaft Center 42.9 mm
- Bearing Housing Material Type PBT
- Shaft Locking Type Set Screw
- Bearing Insert Material 52100 Chrome Steel
- Series Corrosion Resistant with USDA-H1 Grease
- Number of Bolts 2
- Bolt Size M10
- Overall Height 83 mm
- Overall Width 46 mm
- Overall Length 162 mm
- Bearing Lubrication Caltex FM EP or Equivalent USDA-H1 Grease
- Dynamic Load Capacity 3,750 lb
- Static Load Capacity 2,030 lb
- Temp. Range -4 Degrees to 230 Degrees F
- Finish None
Manufacturer Details
- Manufacturer: NTN
- Condensed Mfg Number: SUCPPL20619
- MPN: SUCPPL206-19
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: ZZ
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Pillow Block Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171511
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 11
- UNSPSC Commodity Name: Pillow block bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 3, 2024 10:16pm UTC
Category: Bearings
