2 Bolt Flng Brg Radial Ball 1 3/4in Bore MPN:SUCFL209-28
2 Bolt Flng Brg Radial Ball 1 3/4in Bore
Our 316 stainless steel pipe bushing with a fitting provides exceptional corrosion resistance for seamless connections in demanding environments across the marine, chemical and oil & gas industries. Our high-quality product ensures secure and long-lasting performance catering to professionals and enthusiasts alike who require durable solutions for their pipe assembly needs.
Get NTN item #SUCFL209-28 from our selection of Hardware Accessories while supporting Veterans 🎖.
Technical Specifications
- Item 2-Bolt Flange Bearing
- Mounted Bearing Item 2-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 1 3/4 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Stainless Steel
- Bearing Insert Material 440C Stainless Steel
- Bolt Hole Center-to-Center 148 mm
- Series Corrosion Resistant with USDA-H1 Grease
- Bolt Size M16
- Overall Height 52.2 mm
- Overall Width 108 mm
- Overall Length 180 mm
- Bearing Lubrication Caltex FM EP or Equivalent USDA-H1 Grease
- Dynamic Load Capacity 5,780 lb
- Static Load Capacity 4,670 lb
- Temp. Range -4 Degrees to 248 Degrees F
- Finish Chrome
- Dimension A 188 mm
- Dimension E 148 mm
- Dimension G 16 mm
- Dimension L 38 mm
- Dimension N 19 mm
- Dimension S 19 mm
Manufacturer Details
- Manufacturer: NTN
- Condensed Mfg Number: SUCFL20928
- MPN: SUCFL209-28
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 3, 2024 10:16pm UTC
Category: Bearings
