Geared Piano Hinge 2-1/4 in W MPN:CHS95HD1
Geared Piano Hinge 2-1/4 in W
This high quality gear piano hinge offers smooth, quiet operation while providing durability and ease of installation with adjustable screws for leveling the door. Available in black finish or stainless steel for both indoor and outdoor use, it's an ideal choice for cabinets, doors, and other applications where a reliable hinge solution is needed.
The PEMKO load-rated anodized aluminum hinge is a rugged, no handed geared hinge won't bend or break like hinges with pins and knuckles. Hinge distributes weight evenly on the door and door frame and is suitable for sagging doors or lids. Features a full-length channel cap and helps seal the gap between door and frame to secure door against prying. Constructed of 6063-T6 aluminum alloy with a minimum 10 countersunk holes per leaf. Hinge has a 180° range of motion. Type: half surface heavy duty. 540-lb. load capacity.
Technical Specifications
- Item Continuous Hinge
- Ligature Resistant No
- Material Aluminum
- Range of Motion 180 Degrees
- Finish Mill Aluminum
- Holes With
- Load Capacity 540.0 lb
- Orientation Non Handed
- Door Leaf Height 11/16 in
- Frame Leaf Height 11/16 in
- Door Leaf Width 1 7/8 in
- Frame Leaf Width 2 in
- Door Leaf Thickness 0.187 in
- Frame Leaf Thickness 0.187 in
- Required Door Thickness 1-3/4 in
- Length 7 ft 11 in
- Hardware Not Included
- Holes per Leaf 16
- Mounting Half Surface
- Standards ANSI/BHMA A156.26-2000, UL 76Y2, UL10C
- Overall Width 4 1/2 in
- UL Fire Rating UL10C
Manufacturer Details
- Manufacturer: Pemko
- Condensed Mfg Number: CHS95HD1
- MPN: CHS95HD1
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8302106030
- GDS Category Name: Piano Hinges
- GDS Family Name: Latches Hasps and Hinges
- GDS Segment Name: Hardware
- UNSPSC: 31162403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Miscellaneous fasteners
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Hinges
- UNSPSC Family ID: 16
- UNSPSC Family Name: Hardware
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
