Plastec Blower Forward Curve 6 in MPN:P15SS2P050

Technical Specifications

• Item Plastec Blower
• Type Direct Drive Forward Curve
• Wheel Dia. (In.) 6 in
• Wheel Width (In.) 3.38 in
• CFM @ 0.125-In. SP 350
• CFM @ 0.200-In. SP 375
• CFM @ 0.250-In. SP 450
• CFM @ 0.500-In. SP 500
• CFM @ 0.750-In. SP 500
• CFM @ 1.000-In. SP 500
• CFM @ 1.250-In. SP 500
• CFM @ 1.500-In. SP 425
• CFM @ 2.000-In. SP 400
• CFM @ 2.500-In. SP 100
• dBA @ 5 Feet 72 dBA
• Max. Inlet Temp. (Deg. F) 140 Degrees F
• Max. Ambient Temp. (F) -13 Degrees F
• Voltage 115/230
• Hz 60 Hz
• Phase 1
• Full Load Amps 4.9/2.45
• Motor HP 1/2 hp
• Motor RPM 3,450 RPM
• Motor Type General Duty, Single Phase
• Motor Enclosure Explosion Proof Fan Cooled, Totally Enclosed Fan Cooled
• Motor Frame 71
• Bearing Type Ball, Ball Bearing, Sealed, Permanently Lubricated
• Shaft Dia. (In.) 14 mm
• Height (In.) 21.93 in
• Width (In.) 13.88 in
• Depth (In.) 17.04 in
• Inlet Dia. (In.) 4.92 in
• Outlet Dia. (In.) 4.47 in
• Wheel Type Forward Curve
• Wheel Material Polypropylene
• Blower RPM 3,450 RPM
• Rotation CCW
• Housing Material Polypropylene
• Housing Finish Polypropylene
• Agency Compliance AMCA and CSA certified, UL Listed
• Includes Motor Mounting Base

Manufacturer Details

• Manufacturer: Plastec
• Condensed Mfg Number: P15SS2P050
• MPN: P15SS2P050

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: US
• CA Prop 65 Wht Label: N

Classification Details

• GDS Category Name: Centrifugal Blowers with Motor
• GDS Family Name: Industrial Blowers and Accessories
• GDS Segment Name: HVAC and Refrigeration
• UNSPSC: 40101601
• UNSPSC Class ID: 16
• UNSPSC Commodity Name: Air circulation and parts and accessories
• UNSPSC Commodity ID: 01
• UNSPSC Commodity Name: Blowers
• UNSPSC Family ID: 10
• UNSPSC Family Name: Heating and ventilation and air circulation
• UNSPSC Segment ID: 40
• UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components

Shipping Details

• Not For Sale In: HI AK PR
