Female Rod End RH 3/8 in Bore 3/8 -24 MPN:NFR6S
Female Rod End RH 3/8 in Bore 3/8 -24
Female rod ends with a right-hand thread and 3/8 bore are essential components for applications that require smooth pivotal movement or angular adjustments. Stainless steel construction ensures durability and resistance to corrosion, making them suitable for use in diverse industries such as agriculture, construction, automotive, aerospace, and manufacturing. Their spherical shape allows for greater alignment tolerances, smooth operation, and self-lubrication, reducing wear and tear on equipment. Moreover, the compact design saves space and enables simple installation, making them ideal for various projects that demand precision and reliability.
This steel spherical rod end is engineered to allow pivoting in the housing to compensate for misalignment in industrial applications. It features 52100 steel ball bearing construction, and carbon steel housing to help provide durability in demanding applications.
Technical Specifications
- Item Nylon/PTFE Race Rod End
- Type Female Studded
- Ball 52100 Steel Spherical
- Thread Right Hand
- Thread Size 3/8"-24
- Stud Length 0.906 in
- Bearings 52100 Steel Spherical Ball
- Housing Carbon Steel
- Construction Follows SAE Specification J1120
- Dimension A 3/8"-24
- Dimension B 0.656 in
- Dimension C 0.906 in
- Dimension E 1.0 in
- Dimension G 1.625 in
- Dimension H 0.937 in
- Dimension J 2.125 in
- Max. Angular Misalignment 12 Degrees
- Static Radial Load 4,100 lb
Manufacturer Details
- Manufacturer: QA1
- Condensed Mfg Number: NFR6S
- MPN: NFR6S
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483308055
- GDS Category Name: Spherical Rod Ends
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171508
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 08
- UNSPSC Commodity Name: Rod end bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
