Grooving Insert: X4GKR2503005FG TGH1050, Solid Carbide MPN:02968211
Grooving Insert: X4GKR2503005FG TGH1050, Solid Carbide MPN:02968211 is available to buy in increments of 2
Grooving Insert: X4GKR2503005FG TGH1050, Solid Carbide
Grooving Insert: X4GKR2503005FG TGH1050, Solid Carbide TiAlSiN Finish, Right Hand, 0.5 mm Cutting Width, 2.6 mm Max Depth, Series X4
Product Information
- : 02968211
- Chip Breaker: FG
- Coating Process: PVD
- Coating/Finish: TiAlSiN
- Corner Radius (mm): 0.05
- Cutting Height (Decimal Inch): 0.8030
- Cutting Height (mm): 20.40
- Cutting Tool Application: Grooving
- Cutting Width (Decimal Inch): 0.0200
- Cutting Width (mm): 0.50
- Full Radius: No
- Insert Hand: Right Hand
- Insert Material: Solid Carbide
- Insert Size: 2503005
- Insert Size Code: 25030050050
- Insert Style: X4GKR
- Lead Angle: 0
- Manufacturer Grade: TGH1050
- Maximum Corner Radius (Decimal Inch): 0.0031
- Maximum Depth of Cut (Decimal Inch): 0.1020
- Maximum Depth of Cut (mm): 2.60
- Maximum Depth of Cut Range (Decimal Inch): 0.1000 to 0.1500
- Maximum Depth of Cut Range (mm): 2.00 to 3.00
- Minimum Corner Radius (Decimal Inch): 0.0008
- Multi-Use Tool: Yes
- Overall Length (Decimal Inch): 1.0010
- Overall Length (mm): 25.44
- Primary Workpiece Material: Universal
- Primary Workpiece Material Code: H; K; O; S
- Rake: Positive
- Rake Angle: 6.00
- Series: X4
- Single Or Double End: Double
- Standards: ISO
Additional Information
- Hazardous Materials: No, oK to Ship Via Air
- Material Safety Data Sheet (MSDS) Required: No
- Country of Origin: SE, Sweden
- TAA Compliant: Yes
- UNSPSC: 23242105
- CA Restricted (Prop 65): Unknown
- Package Length: 2.75
- Package Width: 6.00
- Package Height: 0.70
- Package Weight: 0.35
- Prohibited States: AK,HI,PR
Product info last updated on January 1, 2025 12:32am UTC
Category: Grooving Inserts
