Pressure Gauge 3-1/2 Dial Size MPN:LFC-220-160-PSI/KPA-G
Free Shipping
In Stock
A pressure gauge is a precise measuring tool used to indicate pressure within fluid systems; this model features a 3-1/2 inch dial face, with the face being easy to read from various angles while providing accurate information about system pressure fluctuations. The rugged construction of this instrument provides protection against harsh environmental conditions while preventing wear and tear ensuring dependability throughout its usage; its pocket watch style case adds further value, rendering the gauge easily portable in its carry case thus allowing for field use within various industries like mechanical or aerospace engineering. Additionally, the pressure range can be selected according to specific project requirements to provide the right fit, making it a cost-effective investment catering to multiple projects where accurate pressure readings are required.
Technical Specifications
- Item Pressure Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 3 1/2 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Brass / Bronze
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Center Back
- Gauge Primary Range Units kPa
- Gauge Primary Range Values 0 to 10
- Gauge Secondary Range Units psi
- Gauge Secondary Range Values 0 to 160
- Gauge Accuracy +/-2.00%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Gauge Mounting Method Surface
- Liquid Filled Yes
- Gauge Primary Range Smallest Graduation 0.5
- Gauge Case Material Fiber Reinforced Nylon
- Gauge Primary Range Numbered Graduations 3
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Bronze
- Gauge Sensor Material Bronze
- Gauge Lens Material Acrylic
- Gauge Filled With Glycerin
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Gauge Special Options Heavy Duty
- Characteristics With Brass, Copper, and Copper Alloy Internals
- For Use With Non Explosive Gas or Liquid That Do Not Crystalize and Corrode Bronze or Copper Alloy
- Calibration Certificate Included No
- Series LFC-220
- Includes Vent Plug
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Span
- Condensed Mfg Number: LFC220160PSIKPAG
- MPN: LFC-220-160-PSI/KPA-G
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
