CPVC Ball Valve Union Socket/FNPT 3/4 in MPN:1839-007C
IntTthLk's 2-8 Modified Bottoming RH tap is ideal for machine threads, providing superior durability and strength even in the toughest applications. Manufactured from cobalt steel with a 2BX Nitride finish, these high-performance tools are designed to deliver smooth performance and exceptional wear resistance in materials such as aluminum alloys, titanium, and hardened steel. The 6-flute straight flute design improves chip removal while the right-hand thread orientation provides efficient machining. This tap offers precise tolerances to ensure thread uniformity and is available in sizes ranging from #2-8UNC to #36-40UNEF. Its versatile design makes it suitable for numerous industries including automotive, aerospace, medical and manufacturing applications where high-quality, durable threads are necessary.
Technical Specifications
- Item Ball Valve
- Body Material CPVC
- Body Style Inline True Union
- General Connection Type Socket
- Valve Structure 2-Piece
- Pipe Size 3/4 in
- Connection Type Socket/FNPT x Socket/FNPT
- Port Full
- Max. Pressure 235 psi @ 73 Degrees F
- Temp. Range 73 Degrees to 140 Degrees F
- Ball Material CPVC
- Seat Material PTFE
- Stem Type Safe-T-Shear(R)
- Handle Type Locking Tee
- Handle Material Polypropylene
- Stem Material CPVC
- Body Seal Material FPM
- Features True Union Design
- Ball Valve Product Group Manual
- Valve Basic Body Material Plastic
- Standards ASTM F 1970, NSF Approved
- Overall Length 4.75 in
Manufacturer Details
- Manufacturer: Spears
- Condensed Mfg Number: 1839007C
- MPN: 1839-007C
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8481805090
- GDS Category Name: Ball Valves
- GDS Family Name: Shut-Off Valves
- GDS Segment Name: Plumbing
- UNSPSC: 40141607
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Valves
- UNSPSC Commodity ID: 07
- UNSPSC Commodity Name: Ball valves
- UNSPSC Family ID: 14
- UNSPSC Family Name: Fluid and gas distribution
- UNSPSC Segment ID: 40
- UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components
Shipping Details
- Not For Sale In: HI AK PR
