Circuit Breaker 45A 3P 600VAC HG MPN:HGL36045

Discount: See in Cart
Free Shipping
In Stock
Brand: Square D
Part #: HGL36045
UPC: 785901683117
SKU
226-CXG-1MAW4
$1,975.29
Circuit Breaker 45A 3P 600VAC HG
H-frame Square D molded case circuit breakers are rated up to 150A and 600VAC and interrupt excessive current flows to protect devices from electrical damage. They're used in construction, oil and gas, control equipment panels, and other industrial and commercial applications. Their current-carrying parts, mechanisms, and trip devices are contained in a molded case.

Technical Specifications

  • Item Molded Case Circuit Breaker
  • Amps 45 A
  • AC Voltage Rating 600V AC
  • Max. AIR Rating 65kA at 240V AC
  • Series HG
  • High Amp Trip Setting 850 A
  • Low Amp Trip Setting 400 A
  • Circuit Breaker Type Standard
  • Number of Poles 3
  • DC Voltage Rating 250/500V DC
  • Terminal Connection Line/Load Lug
  • Trip Type Thermal Magnetic
  • Phase 3
  • Instantaneous Trip Fixed
  • Phase Connection ABC
  • Frame Size 150A/HG
  • Circuit Breaker Mounting Style Free Standing
  • Height 6.4 in
  • Width 4.12 in
  • Depth 4.36 in
  • Min. Wire Size 14 AWG
  • Max. Wire Size 3 AWG
  • Circuit Breaker Actuator Toggle
  • Max. Operating Temp. 104 Degrees F
  • Standards CE, CSA, IEC, UL Listed

Manufacturer Details

  • Manufacturer: Square D
  • Condensed Mfg Number: HGL36045
  • MPN: HGL36045

Label Details

  • Hazardous Material: Y
  • Green Material Flag: N
  • Country of Origin: ZZ
  • CA Prop 65 Wht Label: N

Classification Details

  • Harmonization Code: 8536200020
  • GDS Category Name: Molded Case Circuit Breakers
  • GDS Family Name: Distribution
  • GDS Segment Name: Electrical
  • UNSPSC: 39121601
  • UNSPSC Class ID: 16
  • UNSPSC Commodity Name: Circuit protection devices and accessories
  • UNSPSC Commodity ID: 01
  • UNSPSC Commodity Name: Circuit breakers
  • UNSPSC Family ID: 12
  • UNSPSC Family Name: Electrical equipment and components and supplies
  • UNSPSC Segment ID: 39
  • UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

  • Not For Sale In: HI AK PR
Related ASINs: B00CONEXFY

Product info last updated on April 3, 2024 11:34pm UTC Category: Distribution
