Transformer 120/240VAC 16/32VAC 150VA MPN:150SV46A

Buck-boost transformer protects connected equipment from damage by reducing (bucking) or raising (boosting) line voltage 5% to 20%. Primary and secondary lead wires can be interconnected for use as an autotransformer. For use in induction motors and air conditioning, lighting, and heating systems.

Technical Specifications

• Item - Transformer Buck Boost Transformer
• Input Voltage - Transformer 120V AC, 240V AC
• Output Voltage - Transformer 16V AC, 32V AC
• VA Rating - Transformer 150 VA
• Phase - Electrical 1
• Hz - Electrical 60 Hz
• Mounting - Transformer Wall
• Outdoor Rated - Transformer Yes
• Temp. Rise 55 Degrees C
• Enclosure Rating NEMA 3R
• IP Rating 54
• Color Gray
• Enclosure Finish Powder Coated
• Height 5.0 in
• Standards carrying cULus Label, CSA Certified via UL, NEMA ST-20, UL Listed
• Depth 3.75 in
• Width 4.85 in
• Knockout Size - Transformer 1/2 in
• Manufacturers Warranty Length 1 yr

Manufacturer Details

• Manufacturer: Square D
• Condensed Mfg Number: 150SV46A
• MPN: 150SV46A

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: US
• CA Prop 65 Wht Label: N

Classification Details

• Harmonization Code: 8504314065
• GDS Category Name: Buck Boost Transformers
• GDS Family Name: Transformers
• GDS Segment Name: Electrical
• UNSPSC: 39121001
• UNSPSC Class ID: 10
• UNSPSC Commodity Name: Power conditioning equipment
• UNSPSC Commodity ID: 01
• UNSPSC Commodity Name: Distribution power transformers
• UNSPSC Family ID: 12
• UNSPSC Family Name: Electrical equipment and components and supplies
• UNSPSC Segment ID: 39
• UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

• Not For Sale In: HI AK PR
