Three Phase Transformer 15kVA 480V MPN:15T68F
Free Shipping
In Stock
Transformers play an essential role in maintaining power supply stability and safety for various electrical loads and machinery. This Three Phase Transformer from Square D is designed specifically to protect sensitive loads from transients and noise in the electrical system. With its 480V input, 15kVA capacity, and both 120V and 208V output options, this transformer delivers a versatile solution for power management across commercial, industrial, or residential environments. The unit's enhanced low-pass filters combined with shielding ensure that even the harshest electrical noise and transients are controlled, offering exceptional reliability and safety. Moreover, it can be used for various applications such as HVAC systems, machinery protection, and UPS backups. With its superior performance, durable construction, and multiple configurable options, this Three Phase Transformer from Square D is the ideal solution to maintain your power supply stability and protect valuable equipment investments.
Top product features:
- Three-phase output voltages (120V AC, 208V AC)
- Enhanced low-pass filters for noise control and transient protection
- Shielding for additional safety
Top product applications:
- Protect sensitive electronics and machinery from power fluctuations in industrial settings
- Provide clean power for server rooms and data centers to ensure consistent performance and uptime
- Support HVAC systems in commercial buildings by stabilizing voltage for efficient operation
Technical Specifications
- Item - Transformer Three Phase Transformer
- Phase - Electrical 3
- Input Voltage - Transformer 480V AC Delta
- Output Voltage - Transformer 120V AC, 208V AC Wye
- VA Rating - Transformer 15 kVA
- Mounting - Transformer Wall
- Outdoor Rated - Transformer Yes
- Voltage Function - Transformer Step Down
- Winding Material - Transformer Copper
- Hz - Electrical 60 Hz
- Temp. Rise 115 Degrees C
- Enclosure Rating NEMA 3R
- IP Rating 54
- Color Gray
- Enclosure Finish Powder Coated
- Enclosure Material Steel
- Width 19.0 in
- Height 14.8 in
- Depth 12.0 in
- Knockout Size - Transformer 1 in, 3/4 in
- Includes FCAN 2 to 2.5%, FCBN 2 to 2.5% Taps
- Standards CSA Certified, cULus, NEMA ST-20, PEP ecopassport, REACh, RoHS, UL Listed
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: 15T68F
- MPN: 15T68F
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8504320000
- GDS Category Name: Three Phase Transformers
- GDS Family Name: Transformers
- GDS Segment Name: Electrical
- UNSPSC: 39121001
- UNSPSC Class ID: 10
- UNSPSC Commodity Name: Power conditioning equipment
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Distribution power transformers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
