Circuit Breaker 20A Bolt On 120/240V 2P MPN:QOB220EPD
Free Shipping
In Stock
Keep your electrical systems safe and secure with our Circuit Breaker 20A Bolt On 120/240V 2P from Square D. Designed for NQOD and NQ panelboards or interiors, these QOB series miniature circuit breakers offer superior stability compared to plug-in or unit-mount models. They instantly detect and interrupt low-level faults in the circuit, providing critical protection against electrical hazards. With a lug orientation that allows for straightforward wiring through bus bars, you'll save time and reduce clutter by eliminating the need to pigtail wires. Ideal for residential, commercial, and industrial applications, this circuit breaker is an essential component of any electrical system. Upgrade your safety today with Circuit Breaker 20A Bolt On 120/240V 2P from Square D.
Top product features:
- Bolt-on installation for added stability compared to plug-in/unit mount circuit breakers.
- Lug orientation for easy straight-in wiring through bus bars, reducing clutter and time spent pigtailing wires.
- Ground fault equipment protection to detect and interrupt low-level faults in the electrical system, providing critical safety features for residential, commercial or industrial applications.
Top product applications:
- Electrical wiring and circuit protection in NQOD and NQ panelboards or interiors for residential, commercial, or industrial applications.
- Protecting electrical systems from ground faults and low-level faults with added stability compared to plug-in/unit mount circuit breakers.
- Organizing wiring through bus bars and eliminating clutter by providing a lug orientation for easy straight-in wiring in load centers.
Technical Specifications
- Item Miniature Circuit Breaker
- Amps 20 A
- AC Voltage Rating 120/240V AC
- Circuit Breaker Type Ground Fault Equipment Protection
- Number of Poles 2
- DC Voltage Rating Not Rated
- Circuit Breaker Actuator Paddle
- Circuit Breaker Mounting Style Bolt On
- Compatible Panelboard/Load Center Series NQ, QO
- Phase Single
- Series QOB
- Max. AIR Rating 10kA at 120/240V AC
- For Use With QO Load Centers and NQ Panelboards
- Terminal Connection Pressure Plate
- Frame Size 100A/QO
- Length 4.12 in
- Width 1.5 in
- Depth 2.91 in
- Min. Operating Temp. 104 Degrees F
- Max. Operating Temp. 104 Degrees F
- Min. Wire Size 12 AWG (Al), 14 AWG (Cu)
- Max. Wire Size 8 AWG
- Standards CSA, UL Listed
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: QOB220EPD
- MPN: QOB220EPD
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Miniature Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121601
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
