Circuit Breaker 30A Bolt On 277V 1P MPN:EDB14030EPD
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-CXG-2JWD5
Circuit Breaker 30A Bolt On 277V 1P
Introducing the Square D Circuit Breaker 30A Bolt On 277V 1P - the ultimate solution for safe and reliable electrical wiring protection! Designed to provide advanced ground fault equipment protection, these miniature circuit breakers are perfect for use in NF panelboards and load centers. With a sturdy bolt-on construction that ensures stability and reduced accidental disconnections, you can trust the Square D Circuit Breaker to provide reliable service in even the most demanding applications. The 30A rating makes it suitable for heavy-duty usage, while the 277V AC voltage rating allows for versatile installation options. Get yours today and experience the peace of mind that comes with the industry's leading electrical protection!
Top product features:
- Bolt-on construction for increased stability
- Ground fault equipment protection
- Lug orientation for easy wiring through bus bars
Top product applications:
- Wiring protection for NF panelboards and load centers
- Ground fault circuit interruption in residential or commercial settings
- Fault current protection in electrical systems that require bolt-on circuit breakers
These EBD and EGB series miniature circuit breakers are bolted into place in NF panelboards, so they're more stable than plug-in or unit-mount circuit breakers. They interrupt currents when low-level faults are detected in the circuit. They have a lug orientation to allow for straight-in wiring through bus bars, which eliminates the need to pigtail wires and helps organize the load center.
Technical Specifications
- Item Miniature Circuit Breaker
- Amps 30 A
- AC Voltage Rating 277V AC
- Circuit Breaker Type Ground Fault Equipment Protection
- Number of Poles 1
- DC Voltage Rating Not Rated
- Circuit Breaker Actuator Toggle
- Circuit Breaker Mounting Style Bolt On
- Compatible Panelboard/Load Center Series NF
- Phase Single
- Series EDB
- Max. AIR Rating 18kA at 120/240V AC
- For Use With Square D NF Panelboards
- Terminal Connection Lug
- Frame Size 125A/EDB
- Length 6.64 in
- Width 1.96 in
- Depth 4.05 in
- Max. Operating Temp. 104 Degrees F
- Min. Wire Size 12 AWG (Al), 14 AWG (Cu)
- Max. Wire Size 4 AWG (Al), 6 AWG (Cu)
- Standards cULus, IEC
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: EDB14030EPD
- MPN: EDB14030EPD
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Miniature Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121601
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Related ASINs: B00CONGTQA
Product info last updated on April 3, 2024 8:27pm UTC Category: Distribution
