Thermocouple Probe Type J Length 3 in. MPN:TMW00017
Thermocouple Probe Type J Length 3 in.
Looking for a reliable and precise temperature measurement solution? Check out our high-quality Thermocouple Probe Type J Length 3 in. from Tempco! Designed with quality craftsmanship, this thermocouple probe is perfect for your industrial applications such as furnaces, boilers, kilns, and chemical processing plants. Our Magnet Thermocouple offers grounded connections and comes equipped with a Type J thermocouple type for superior accuracy. With a compact 1.25-inch probe length and Fork Terminal plug or connector type, it's the perfect size to fit into tight spaces while still delivering reliable readings. Made in the USA by our Veteran-Owned Business, you can trust its quality and durability.
Top product features:
- Magnet Thermocouple
- Grounded connection
- Type J thermocouple type
Top product applications:
- Industrial temperature measurements in furnaces, boilers, kilns, and chemical processing plants
- Temperature monitoring in high-heat environments
- Temperature measurement in metalworking processes
Buy Tempco item #TMW00017 ✯ Made in the USA ✯ and sold by a Veteran-Owned Business.
Technical Specifications
- Item Magnet Thermocouple
- Grounded / Ungrounded Grounded
- Thermocouple Type J
- Probe Length 1.25 in
- Plug or Connector Type Fork Terminal
- Material 304 Stainless Steel
- Insulation PTFE
- Lead Length 6 ft
- Error Accuracy (Deg. C) +/-2.2
- Error Accuracy (%) +/-0.75
- Temp. Limit (Deg. F) 752
- Thermocouple Element 20 AWG
- Construction Spring-loaded thermocouple Attached to 6-pole Magnet
Manufacturer Details
- Manufacturer: Tempco
- Condensed Mfg Number: TMW00017
- MPN: TMW00017
Label Details
- Hazardous Material: Y
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9025198085
- GDS Category Name: Thermocouple Probes
- GDS Family Name: Temperature and Humidity Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112206
- UNSPSC Class ID: 22
- UNSPSC Commodity Name: Temperature and heat measuring instruments
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Thermocouples
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on January 25, 2024 1:44pm UTC
Category: Temperature and Humidity Measuring
