Thread Forming Tap: #2-56 UNC, 2BX Class of Fit, Semi-Bottoming, High Speed Steel, TiN Coated MPN:7427633

Discount: See in Cart
Free Shipping
In Stock
Brand: Walter
Part #: 7427633
SKU
310-95977757
Thread Forming Tap: #2-56 UNC, 2BX Class of Fit, Semi-Bottoming, High Speed Steel, TiN Coated

The Thread forming tap is an ideal tool when working with delicate materials like brass, aluminum, copper alloys or hardened steel to create accurate threads without damaging the material while cutting reducing stripping issues ensuring quality control on aerospace or medical industries where precise tolerances are required. Tapered roller bearings allow for an easy entry in tapped holes bringing ease of use during set up reducing downtime allowing for a longer lifespan delivering consistent threads time and time again, increasing productivity across applications while the TiN coating increases durability reducing maintenance costs promoting sustainable manufacturing. #2-56UNC size offers versatility perfect when working in electronics, automotive industries or any threaded component where a high class of fit is required offering peace of mind on consistent outcomes making it essential tool among industry professionals and hobbyists alike.

Thread Forming Tap: #2-56 UNC, 2BX Class of Fit, Semi-Bottoming, High Speed Steel, TiN Coated 7 mm Thread Length, 45 mm OAL, Series TC410

Product Information

  • : 7427633
  • Application: Blind Hole Threading; Through-Hole Threading
  • Chamfer: Modified Bottoming
  • Chamfered Threads: 2-3P
  • Class of Fit: 2BX
  • Coating/Finish: Titanium Nitride
  • Coolant Through: No
  • Flute By Diameter Ratio: 3.5xD
  • Material: High-Speed Steel-E
  • Material Application: Steel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloy
  • Material Application Code: P; M; K; N; S
  • Material Grade: WY80AD
  • Oil Grooves: 3
  • Overall Length (Decimal Inch): 1.7717
  • Overall Length (mm): 45.00
  • Series: TC410
  • Shank Diameter (Decimal Inch): 0.1102
  • Square Size (Decimal Inch): 0.0827
  • Tapping Depth (Decimal Inch): 0.4724
  • Tapping Depth (mm): 12.00
  • Thread Direction: Right Hand
  • Thread Length (Decimal Inch): 0.2756
  • Thread Length (mm): 7.00
  • Thread Size (Inch): #2-56
  • Thread Standard: UNC
  • Trade Name: TC410 Advance

Additional Information

  • Hazardous Materials: No, oK to Ship Via Air
  • Country of Origin: DE, Germany
  • TAA Compliant: Yes
  • UNSPSC: 23241600
  • CA Restricted (Prop 65): Unknown
  • Package Length: 3.19
  • Package Width: 0.39
  • Package Height: 0.35
  • Package Weight: 0.02
  • Prohibited States: AK,HI,PR
