Thread Forming Tap: M6 Metric, 6HX Class of Fit, Semi-Bottoming, High Speed Steel, TiN Coated MPN:7427627
Thread Forming Tap: M6 Metric, 6HX Class of Fit, Semi-Bottoming, High Speed Steel, TiN Coated
Thread Forming Tap: M6 Metric, 6HX Class of Fit, Semi-Bottoming, High Speed Steel, TiN Coated 80 mm OAL, Series TC410
Product Information
- : 7427627
- Application: Blind Hole Threading; Through-Hole Threading
- Chamfer: Modified Bottoming
- Chamfered Threads: 2-3P
- Class of Fit: 6HX
- Coating/Finish: Titanium Nitride
- Coolant Through: No
- Flute By Diameter Ratio: 3.5xD
- Material: High-Speed Steel-E
- Material Application Code: P; M; K; N; S
- Material Grade: WY80AD
- Oil Grooves: 5
- Overall Length (Decimal Inch): 3.1496
- Overall Length (mm): 80.00
- Series: TC410
- Shank Diameter (Decimal Inch): 0.2362
- Shank Diameter (mm): 6.00
- Square Size (Decimal Inch): 0.1929
- Square Size (mm): 4.90
- Tapping Depth (Decimal Inch): 1.1811
- Tapping Depth (mm): 30.00
- Thread Direction: Right Hand
- Thread Length (Decimal Inch): 0.5906
- Thread Length (mm): 15.00
- Thread Size (mm): M6x1
- Thread Standard: Metric
- Trade Name: TC410 Advance
Additional Information
- Hazardous Materials: No, oK to Ship Via Air
- Country of Origin: Coo Data Unavail
- TAA Compliant: No
- UNSPSC: 23241600
- CA Restricted (Prop 65): Unknown
- Package Length: 3.15
- Package Width: 0.39
- Package Height: 0.35
- Package Weight: 0.04
- Prohibited States: AK,HI,PR
Product info last updated on October 1, 2024 12:25am UTC
Category: Thread Forming Taps
