Thread Forming Tap: #6-40 UNF, 2BX Class of Fit, Semi-Bottoming, High Speed Steel, TiN Coated MPN:7427649
Thread Forming Tap: #6-40 UNF, 2BX Class of Fit, Semi-Bottoming, High Speed Steel, TiN Coated
Thread Forming Tap: #6-40 UNF, 2BX Class of Fit, Semi-Bottoming, High Speed Steel, TiN Coated 13 mm Thread Length, 56 mm OAL, Series TC410
Product Information
- : 7427649
- Application: Blind Hole Threading; Through-Hole Threading
- Chamfer: Modified Bottoming
- Chamfered Threads: 2-3P
- Class of Fit: 2BX
- Coating/Finish: Titanium Nitride
- Coolant Through: No
- Flute By Diameter Ratio: 3.5xD
- Material: High-Speed Steel-E
- Material Application: Steel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloy
- Material Application Code: P; M; K; N; S
- Material Grade: WY80AD
- Oil Grooves: 4
- Overall Length (Decimal Inch): 2.2047
- Overall Length (mm): 56.00
- Series: TC410
- Shank Diameter (Decimal Inch): 0.1575
- Shank Diameter (mm): 4.00
- Square Size (Decimal Inch): 0.1181
- Square Size (mm): 3.00
- Tapping Depth (Decimal Inch): 0.7874
- Tapping Depth (mm): 20.00
- Thread Direction: Right Hand
- Thread Length (Decimal Inch): 0.4331
- Thread Length (mm): 11.00
- Thread Size (Inch): #6-40
- Thread Standard: UNF
- Trade Name: TC410 Advance
Additional Information
- Hazardous Materials: No, oK to Ship Via Air
- Material Safety Data Sheet (MSDS) Required: No
- Country of Origin: DE, Germany
- TAA Compliant: Yes
- UNSPSC: 23241600
- CA Restricted (Prop 65): Unknown
- Package Length: 3.15
- Package Width: 0.39
- Package Height: 0.35
- Package Weight: 0.02
- Prohibited States: AK,HI,PR
Related ASINs: B09ZTTH7TZ, B00FXJTTKA, B07Y58H43X
Product info last updated on October 1, 2024 1:46am UTC Category: Thread Forming Taps
